| Item | CJ Series Hub |
|---|---|
| Angular Displacement | 1/25" |
| Bore Size | 24 mm |
| Bore Type | Bored |
| Color | Metallic |
| Coupling Type | Jaw |
| Dimension G | 17.78 mm |
| Dimension Hd | 55.88 mm |
| Distance Between Spider And Hub Face (dimension Cl) | 2.03 mm |
| Hub Material | Powder Metal |
| Hub Type | B |
| Keyway | Keyway |
| Keyway Size | 8 mm x 3.3 mm |
| Length Through Bore | 29.97 mm |
| Max. Angular Displacement (Δ Ka), N=1500 [1/min] | 0.9° |
| Max. Axial Displacement | 0.055" |
| Max. Bore | 32 mm |
| Max. Operating Temp. | -50°F to +248°F |
|---|---|
| Max. Radial Displacement | 0.009" |
| Max. Torque | 70 N-m |
| Min. Bore | 18 mm |
| Nominal Torque (with 92 Shore A Spider) | 35 N-m |
| Normal Temperature Range (with 80 Shore A, 92 Shore A, And 95/98 Shore A Spiders) | -40°F to +212°F |
| Outside Dia. | 55.88 mm |
| Overall Coupling Length | 45.72 mm |
| Screw Size | #10-24 |
| Screw Thread Per Inch | #10-24 |
| Set Screw Style Coupling Location Size | 9.91 mm |
| Speed | 10600 RPM |
| Spider Inside Dia. | 27 mm |
| Spider Outside Dia. | 55 mm |
| Spider Thickness (dimension W) | 14 mm |
| Style | Bored |
| System Of Measurement | Metric |
| Height (cm) | 9.14 |
|---|---|
| Length (cm) | 5.59 |
| Width (cm) | 5.59 |
| Country Of Origin | US |
|---|---|
| Weight (kg) | 0.4455 |
