| Item | Doughnut Coupling Element |
|---|---|
| Bolt Grade | #5 |
| Bolt Length | 3 1/4" |
| Bolt Size | 5/8"-11 |
| Color | Black |
| Complete Coupling Weight | 31 lbs. |
| Coupling | S22 |
| Coupling Type | Torsional |
| Dimension Bc | 5 1/5" |
| Dimension Hd | 3 22/25" |
| Dimension L | 2.06" |
| Dimension W | 2.06" |
| Dynamic Torsional Stiffness | 22918 lbs.-in./deg. |
| Features | No End Thrust In Misalignment Position Absorbs Misalignment And Shock No Axial Reaction Force To Damage Or Accelerate Wear In System Bearings Accepts Constant Angular Misalignment Of Up To 3° Parallel Tolerance Of 0.060 (1.5Mm), While Reaction Force Remains Low Lateral Softness Without Complication, Or Sacrifice Of Performance Or Durability Natural Rubber Can Operate In Temperatures From -60° To 200° F (-51° To 93° C) |
| Insert Style | Donut Type |
| Material | Natural Rubber |
| Max. Bore (dimensions Id1/id2) | 2 1/2" |
| Max. Shock Load | 9000 lbs.-in. |
|---|---|
| Max. Speed | 5000 RPM |
| Moment Of Inertia Wr2 | 102 lbs.-sq. in. |
| No. Of Bolts | 6 |
| Normal Temperature Range | -60°F to +200°F |
| Outside Dia. | 7.31" |
| Overall Length | 8.69" |
| Rated Hp At 100 Rpm For 1.0 Service Factor | 119/25 hp |
| Rated Torque At 1.0 Sf | 3000 lbs.-in. |
| Rated Torque For 1.0 Service Factor | 3000 lbs.-in. |
| Recommended Torque (dry) | 150 lbs.-ft. |
| Recommended Torque (wet) | 110 lbs.-ft. |
| Set Screw Thread Size (dimension T) | No Setscrew |
| Specific Torsional Stiffness | 7.64 lbs.-in./deg. |
| Type | Flexible |
| Volume | 110.07837 cu. in. |
| Height (cm) | 22.07 |
|---|---|
| Length (cm) | 10.16 |
| Width (cm) | 10.16 |
| Country Of Origin | US |
|---|---|
| Weight (kg) | 2.322 |
