| Item | Metric Motor |
|---|---|
| Ambient Temp. | 40°C |
| Amps | 1.7A |
| Assembly | M1040297 |
| Drive End Bearing Size | 6201-13 |
| Drive End Bearing Type | Ball |
| Duty Cycle | S1 |
| Efficiency | 73% |
| Explosion Proof | Brake Motors |
| Form Factor | 1.05 |
| Form Factor 2 | 1.4 |
| Frame | 63D |
| Frame Length | 7.18" |
| Frame Size | 63D |
| Frame Suffix | D |
| Grease Type | Polyrex EM |
| Height | 6 1/2" |
| Inertia | 10.3 oz./sq. in. |
| Insulation Class | Class F |
| Ip Rating | IP54 |
| Kw | 0.25 kW |
| Kw2 | 0.18 kW |
| Length | 11 1/2" |
| Lubrication | Polyrex EM |
| Max. Ambient Temp. | 40°C |
|---|---|
| Motor Shaft Rotation | Reconn |
| Mounting Type | B14 |
| Nameplate Rpm | 3000 RPM |
| Nominal Efficiency | 73% |
| Opp. Drive End Bearing Size | 6201-13 |
| Opp. Drive End Bearing Type | Ball |
| Outline | M1030280 |
| Output Kw | 0.25 kW |
| Overall Length | 8.78" |
| Packaging | M1307020.02 |
| Power | 0.25 kW |
| Rotation Type | Reversible |
| Rpm | 3000 RPM |
| Service Factor | 1 |
| Shaft Dia. | 0.437" |
| Shaft Length | 0.905" |
| Test Card | 03 |
| Thermal Protection | No Protection |
| Torque | 81.1 oz.-in. |
| Type | G63-9 |
| Voltage | 180V |
| Winding | MD342149 |
| Height (cm) | 16.51 |
|---|---|
| Length (cm) | 29.21 |
| Width (cm) | 19.05 |
| Country Of Origin | US |
|---|---|
| Weight (kg) | 4.5 |
| Style | Model | Frame | Nominal Efficiency | Shaft Dia. | Shaft Length | Power | Type | Amps | Overall Length | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | M1130139.00 | 63D | 74.4% | 0.437" | 0.91" | 0.25 kW | G63-9 | 1.7A | 9 1/2" | $714.68 | |
| B | M1130141.00 | 56D | 71.6% | 3/8" | 0.788" | 0.18 kW | E56-9 | 1.2A | 7.54" | $610.47 | |
| C | M1130143.00 | 63D | 75.8% | 0.437" | 0.91" | 0.37 kW | G63-9 | 2.4A | 9 1/2" | $583.91 |
