| Item | Single Phase Motor |
|---|---|
| Ambient Temp. | 40°C |
| Amps | 2.3/4.6A |
| Application Type | General Purpose Ac Motors |
| Assembly/box Mounting | F1 Only |
| Bearing Type | Ball |
| Code | K |
| Conduit Box Position | F1 |
| Curvepoint | Pull Up |
| Design Code | No |
| Drive End Bearing Size | 6203 |
| Drive End Bearing Type | Ball |
| Duty Cycle | Continuous |
| Efficiency | 76.2% |
| Electrical Type | Capacitor Start, Capacitor Run |
| Enclosure Type | ODP |
| Frame | 56C |
| Frame Length | 7 1/2" |
| Frame Material | Rolled Steel |
| Frame Prefix | S |
| Frame Size | S56C |
| Frame Suffix | C |
| Frequency | 60 Hz |
| Full Load Amps | 4.6/2.3A |
| Height | 8 3/4" |
| Hp | 1/2 hp |
| Hz | 60 Hz |
| Ins. Class | Class B |
| Insulation Class | Class B |
| Inverter Rated | No |
| Ip Code | IP22 |
| Kva Code | K |
| Kw | 0.37 kW |
| Length | 13 3/4" |
| Load | 1 |
| Manufacturers Warranty Length | 1 yr. |
| Material | Rolled Steel |
| Max. Ambient Temp. | 104°F |
| Motor Application | General Application |
| Motor Bearings | Ball |
| Motor Design | Capacitor Start/Run |
| Motor Enclosure Design | Open Dripproof |
| Motor Frame Material | Steel |
| Motor Mounting Position | Horizontal |
|---|---|
| Motor Mounting Type | Face |
| Motor Orientation | Horizontal |
| Motor Service Factor | 1.25 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Type | Capacitor Start/Run |
| Mounting Type | Round, C Face Footless |
| Nameplate Rpm | 1725 RPM |
| Nema Design | B |
| Nema Rating | NEMA 56 |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 76.2% |
| Opp. Drive End Bearing Size | 6203 |
| Opp. Drive End Bearing Type | Ball |
| Output Kw | 0.37 kW |
| Overall Length | 11.49" |
| Packaging | F |
| Phase | 1 |
| Power Factor | 91.6 |
| Resistance Main | 0 ohms |
| Rotation Type | Selective CCW |
| Rpm | 1725 RPM |
| Service Factor | 1.25 |
| Shaft Dia. | 5/8" |
| Shaft Length | 1 22/25" |
| Special Features | Capacitor Start Motors |
| Starting Method | Across The Line |
| Synchronous Rpm | 1800 RPM |
| Thermal Protection | No Protection |
| Torque | 75.4 lbs.-ft. |
| Torque Rating | 24.4 lbs.-ft. |
| Torquepct | 309 |
| Type | KD |
| Usable @ 200v | No |
| Usable @ 208v | No |
| Variable Torque Speed Range | 10 |
| Voltage | 115/230V AC |
| Voltage Rating | 115/230V AC |
| Width | 6.17" |
| Motor Thermal Protection | None |
| Standards | CE CERTIFIED, CSA CERTIFIED, UL LISTED |
| Height (cm) | 22.22 |
|---|---|
| Length (cm) | 34.92 |
| Width (cm) | 20.02 |
| Country Of Origin | MX |
|---|---|
| Weight (kg) | 9.9 |
