| Item | General Purpose Motor |
|---|---|
| Ambient Temp. | 104°F |
| Amps | 8/4A |
| Bearing Type | Ball |
| Code | M |
| Conduit Box Position | F1 |
| Design Code | B |
| Drive End Bearing Size | 6205 |
| Drive End Bearing Type | Ball |
| Duty Cycle | Continuous |
| Efficiency | 86.5% |
| Electrical Type | Squirrel Cage, Induction Run |
| Enclosure Type | Tefc |
| Frame | 145TC |
| Frame Length | 8" |
| Frame Material | Rolled Steel |
| Frame Type | 145TC |
| Frequency | 60 Hz |
| Full Load Amps | 8.8-8/4A |
| Grease Type | Polyrex EM |
| Height | 10 22/25" |
| Hp | 3 hp |
| Hz | 60 Hz |
| Ins. Class | Class F |
| Insulation Class | Class F |
| Ip Code | IP43 |
| Kva Code | M |
| Kw | 2.2 kW |
| Length | 19 1/2" |
| Lubrication | Polyrex EM |
| Max. Ambient Temp. | 40°C |
| Max. Rpm | 3490 RPM |
| Motor Application | General Application |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Totally Enclosed Air Over |
| Motor Frame Material | Steel |
| Motor Mounting Position | Horizontal |
|---|---|
| Motor Mounting Type | Face |
| Motor Orientation | Horizontal |
| Motor Service Factor | 1.15 |
| Motor Shaft Design | T |
| Motor Shaft Rotation | Reversible |
| Motor Type | Three Phase |
| Mounting Type | Face |
| Nameplate Rpm | 3600 RPM |
| Nema Design | B |
| No. Of Poles | 2 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 86.5% |
| Opp. Drive End Bearing Size | 6203 |
| Opp. Drive End Bearing Type | Ball |
| Output Kw | 2.24 kW |
| Overall Length | 13 15/16" |
| Packaging | B |
| Phase | 3 |
| Power Factor | 86 |
| Removable Base | Permanently Lubricated Bearings |
| Resistance Main | 3.83 ohms |
| Rpm | 3400-3600 RPM |
| Rpm Range | 3001-3600 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 7/8" |
| Shaft Length | 2 1/4" |
| Shaft Type | T |
| Standards | Csa, Ul |
| Starting Method | Across The Line |
| Thermal Protection | No Protection |
| Type | TF |
| Usable @ 208v | Yes |
| Voltage | 208-230/460V |
| Width | 10 11/25" |
| Motor Thermal Protection | None |
| Height (cm) | 27.64 |
|---|---|
| Length (cm) | 49.53 |
| Width (cm) | 26.52 |
| Country Of Origin | US |
|---|---|
| Weight (kg) | 21.15 |
| Style | Model | Voltage | Nameplate Rpm | Hp | Frequency | Full Load Amps | Mounting Type | Motor Type | Service Factor | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 101769.00 | 208-230/460V | 1725 RPM | 33/100 hp | 60 Hz | 1.5-1.6/0.8A | Face | Three Phase | 1.15 | $687.78 | |
| B | 101780.00 | 208-230/460V | 1800/1500 RPM | 1/2 hp | 60 Hz | 1.8/0.9A | C Face, Footless | Squirrel Cage Induction Run | 1.15 | $610.40 | |
| C | 101981.00 | 208-230V | 1800 RPM | 1/4 hp | 60 Hz | 1.2-1.4/0.7A | Rigid Base | Squirrel Cage Induction Run | 1.15 | $386.96 | |
| D | 102860.00 | 208-230/460V | 1725 RPM | 1/2 hp | 60 Hz | 1.9-2/1A | Face | Three Phase | 1.15 | $474.70 | |
| E | 102863.00 | 208-230/460V | 1800 RPM | 33/100 hp | 60 Hz | 1.3/0.65A | C Face, Footless | Squirrel Cage Induction Run | 1.15 | $417.47 | |
| F | 110047.00 | 208-230/460V | 1725 RPM | 3/4 hp | 60 Hz | 2.8/1.4A | Face | Squirrel Cage Induction Run | 1.15 | $512.84 | |
| G | 110144.00 | 208-230/460V | 3600 RPM | 1/2 hp | 60 Hz | 1.7-1.6/0.8A | C Face, Footless | Squirrel Cage Induction Run | 1.15 | $486.69 |
