| Item | DC Motor |
|---|---|
| Amps | 14A |
| Bearing Type | Ball |
| Brush Type | External |
| Drive End Bearing Size | 6205 |
| Drive End Bearing Type | Ball |
| Duty Cycle | Continuous |
| Efficiency | 88.8% |
| Enclosure Type | Tefc |
| Form Factor | 1.38 |
| Frame | 143/5TC |
| Frame Type | 182/145TC |
| Full Load Amps | 14A |
| Full Load Torque | 108 lbs.-in. |
| Grease Type | Polyrex EM |
| Hp | 3 hp |
| Ins. Class | Class H |
| Insulation Class | Class H |
| Kw | 2.2 kW |
| Length Less Shaft | 17 7/16" |
| Lubrication | Polyrex EM |
| Max. Ambient Temp. | 40°C |
| Motor Application | General Application |
|---|---|
| Motor Bearings | Ball |
| Motor Design | Permanent Magnet DC |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Mounting Type | Face, Base |
| Motor Shaft Rotation | Clockwise/Counter Clockwise |
| Mounting Type | Face/Base |
| Nameplate Rpm | 1750 RPM |
| Opp. Drive End Bearing Size | 6204 |
| Opp. Drive End Bearing Type | Ball |
| Overall Length | 19 5/8" |
| Power | 2.2 kW |
| Rpm | 1700-1800 RPM |
| Service Factor | 1 |
| Shaft Dia. | 7/8" |
| Shaft Length | 2.15" |
| Thermal Protection | None |
| Type | DF |
| Voltage | 180V |
| Motor Thermal Protection | None |
| Standards | CSA (LR2025), UL (E49747) |
| Height (cm) | 30.48 |
|---|---|
| Length (cm) | 65.02 |
| Width (cm) | 37.08 |
| Country Of Origin | US |
|---|---|
| Weight (kg) | 39.6 |
