| Item | Electric Actuator |
|---|---|
| Ambient Temp. | 140°F |
| Application | Dampers |
| Control Signal | On/Off |
| Cycle Time | 55 sec. to 71 sec. |
| Depth | 2 1/4" |
| Electrical Connection Type | Hardwired |
| Enclosure Rating | NEMA 2, IP54 |
| For Shaft Dia. | 5/8" |
| For Shaft Diameter | 5/8" |
| For Shaft Height | Not Applicable |
| For Shaft Shape | Round |
| For Shaft Width | Not Applicable |
| For Use With Building Automation Systems | Building Automation System Compatible |
| Includes | Anti-Rotation Bracket |
| Input Voltage | 120V AC |
| Ip Rating | IP54 |
| Maximum Operating Temperature | 140°F |
| Minimum Operating Temperature | -40°F |
| Mounting Type | Direct Mount |
| Nema Rating | 2 |
|---|---|
| Number Of Auxiliary Switches | 0 |
| Operating Temperature | -40°F to +140°F |
| Overall Depth | 2 1/4" |
| Overall Height | 6 3/8" |
| Overall Width | 3 7/8" |
| Power Consumption | 0.05A |
| Product Type | Actuator |
| Rated Torque | 70 lbs.-in. |
| Replaces Honeywell Motors | Mfr. No. Ms4105A1030 |
| Return Action | Spring Return |
| Shaft Rotation | CW/CCW |
| Shaft Type | Self Centering Clamping |
| Stroke Deg. | 90° |
| System Application | Dampers |
| Time To Close | 75 sec. |
| Torque | 70 lbs.-in. |
| Voltage | 24V AC |
| Width | 3 7/8" |
| Height (cm) | 16.19 |
|---|---|
| Length (cm) | 5.72 |
| Width (cm) | 9.84 |
| HS Code | 8501104060 |
|---|---|
| Country Of Origin | MX |
| Weight (kg) | 2.025 |
| Style | Model | Cycle Time | Signal Type | Power Consumption | Mounting Type | Replaces Honeywell Motors | Torque | Product Type | Voltage | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | M9208-AGA-2 | - | Floating Point | 7.9 VA | Direct Mount | - | 70 lbs.-in. | Actuator | - | $476.73 | |
| A | M9208-AGA-3 | - | Floating Point, On/Off | 7.9 VA | Direct Mount | - | 70 lbs.-in. | - | - | $329.40 | |
| A | M9208-AGC-3 | - | Floating Point | 7.9 VA | Direct Mount | - | 70 lbs.-in. | Actuator | - | $435.83 | |
| A | M9208-BAC-3 | 55 sec. to 71 sec. | - | 0.05A | Direct | Mfr. No. Ms4105A1130 | 70 lbs.-in. | - | 24V AC | $574.89 | |
| A | M9208-BDC-3 | 55 sec. to 71 sec. | - | 0.04A | Direct Mount | - | 70 lbs.-in. | Actuator | 24V AC | $592.39 | |
| A | M9208-BGA-3 | 55 sec. to 71 sec. | - | 6.1 VA | Direct Mount | Mfr. No. Ms8105A1008 | 70 lbs.-in. | Actuator | 24V AC | $427.07 | |
| A | M9208-BGC-3 | 55 sec. to 71 sec. | - | 6.1 VA | Direct Mount | - | 70 lbs.-in. | Actuator | 24V AC | $494.44 |
