HOFFMAN DAH8001B Fan Forced Enclosure Heater 800W 115V

Item: AG2RYU
Model: DAH8001B
Cross Ref: 32FL02
21 In Stock.

Ships within 2 days via

We deliver to your doorstep under DAP terms. Customs clearance is for your account

$1,115.20
10% off
$1,003.68 /unit (ex. VAT)
Add To Cart
Request Quote

Unlock 30-day payment terms

Business customers can apply for Net 30
No fees, No interest, Fast approval.

FREE delivery on orders over $ 150.00

Payment

Specifications

Item Fan Forced Enclosure Heater
Heater Type Fan Forced
Height 7 1/2"
Includes (4) Self-Tapping Screws
Includes Thermostat Thermostat Included
Length 5.187"
Mounting Dimension 4 1/2" x 4 1/4"
Mounting Holes On Center Spacing 7" H x 3.50" W
Operating Voltage 115V AC
Overall Height 7 1/2"
Overall Length 7 1/2"
Overall Width 4 3/10"
Phase 1
Thermostat Setpoint - Maximum 100°F
Thermostat Setpoint - Minimum 0°F
Wattage 800 W
Width 4 1/4"
standard CE, CSA CERTIFIED, CSA FILE NO. LR42186, FILE NO. E61997, UL 508A COMPONENT RECOGNIZED

Product Details

Hoffman DAH8001B fan forced enclosure heater protects industrial equipment from low temperatures and condensation by maintaining a stable enclosure temperature.

Shipping Information

Height (cm) 15.24
Length (cm) 21.59
Width (cm) 15.24
HS Code 8516290090
Country Of Origin US
Weight (kg) 1.1025

Working Mechanism

  • The fan draws cool air from the enclosure's bottom and circulates it past the thermostat and heating element before releasing it into the enclosure cavity.
  • The heated air is then released through the heater unit's top.

Features

  • Hoffman DAH8001B fan forced enclosure heater has a terminal strip with a clamp connector that accepts both solid and stranded wire.
  • It has a ball-bearing fan to circulate air throughout the workspace.
  • This unit has aluminium housing that resists corrosion and its brushed finish offers aesthetic appearnace.

Standards and Approvals

  • CE
  • CSA
  • UL
  • cUL
  • NEMA
  • RoHS
  • REACH

Certifications

certificatecertificatecertificate

Frequently Asked Questions

What is the temperature control range of this Hoffman enclosure heater?

0 to 100 degrees F.

Should a heater be placed high or low?

Warm air tends to rise over cool air. So place this heater at lower levels for optimised heating.

How to install this heater on walls?

This unit comes with four self-tapping screws for easy mounting on walls.

Can this unit handle moisture?

Hoffman DAH8001B enclosure heater is IP54-rated and can be used in wet conditions.
