| Item | Hydraulic Gear Pump/Motor |
|---|---|
| Dimension A | 3 4/25" |
| Discharge Connection Size | 9/16"-18 |
| Displacement | 0.097 cu. in./rev. |
| Displacement Per Revolution | 0.097 cu. in./rev. |
| Gpm @ 1800 Rpm & 1000 Psi | 0.6 GPM |
| Gpm @ 3600 Rpm & 1000 Psi | 1.2 GPM |
| Housing | Cast Iron |
| Housing Material | Cast Iron |
| Intake Connection | 9/16"-18 Sae |
| Max. Continuous Pressure | 3000 psi |
| Max. Intermittent Pressure | 3500 psi |
| Max. Speed | 5000 RPM |
| Media Intake Connection Size | 9/16"-18 |
| Media Intake Connection Type | SAE |
|---|---|
| Motor Speed (maximum) | 5000 RPM |
| Motor Speed (minimum) | 500 RPM |
| Mounting Type | 4 Bolt 4F17 |
| Nominal Gpm @ 1200 Rpm | 0.5 GPM |
| Overall Height | 3.3" |
| Overall Length | 4.7" |
| Overall Width | 3.3" |
| Rotation | CW/CCW |
| Shaft Extension (in.) | 1/2" x 1 1/2" |
| Shaft Outer Diameter | 1/2" |
| Shaft Type | Keyed |
| Type | Birotational |
| Height (cm) | 12.19 |
|---|---|
| Length (cm) | 10.92 |
| Width (cm) | 10.92 |
| HS Code | 8413919050 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 2.205 |
| Style | Model | Displacement | Max. Continuous Pressure | Dimension A | Gpm @ 3600 Rpm & 1000 Psi | Max. Intermittent Pressure | Nominal Gpm @ 1200 Rpm | Overall Length | Overall Width | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 1002496 | 0.065 cu. in./rev. | 3000 psi | 3 4/25" | 0.8 GPM | 3500 psi | 0.3 GPM | 4.7" | 3.3" | $317.49 | |
| A | 1002498 | 0.129 cu. in./rev. | 3000 psi | 3 4/25" | 1.6 GPM | 3500 psi | 0.7 GPM | 4.7" | 3.3" | $327.47 | |
| A | 1070054 | 0.258 cu. in./rev. | 3000 psi | 3 4/25" | 3.3 GPM | 3500 psi | 1.3 GPM | 5.2" | 3.3" | $365.47 | |
| A | 1070043 | 0.323 cu. in./rev. | - | 3.69" | 4.1 GPM | 3500 psi | 1.7 GPM | 5.2" | 3.3" | $412.43 | |
| A | 1070045 | 0.388 cu. in./rev. | 3000 psi | 3.69" | 5 GPM | 3300 psi | 2 GPM | 5.2" | 3.3" | $376.10 | |
| A | 1070047 | 0.453 cu. in./rev. | 2750 psi | 3.69" | 5.8 GPM | 3025 psi | 2.4 GPM | 5.2" | 3.3" | $412.37 | |
| A | 1070049 | 0.517 cu. in./rev. | 2500 psi | 3.69" | 6.6 GPM | 2750 psi | 2.7 GPM | 5.2" | 3.1" | $374.83 |
