| Item | Lock Nut |
|---|---|
| Class | Class 8 |
| Dimensional Standards | D980V |
| Finish | Zinc Plated |
| Hex Height | 10 mm |
| Hex Type | Standard Hex Top Lock |
| Hex Width | 17 mm |
| Lock Type | Top Lock Distorted Thread |
| Material | Steel |
| Material Grade/class | Class 8 |
|---|---|
| Nut Height | 10 mm |
| Nut Type | Top Lock Distorted Thread |
| System Of Measurement | Metric |
| Thread Direction | Right Hand |
| Thread Size | M10 x 1.25 |
| Thread Type | Fine |
| Type | Standard Hex Top Lock |
| Height (cm) | 2.54 |
|---|---|
| Length (cm) | 38.1 |
| Width (cm) | 17.78 |
|---|---|
| Weight (kg) | 1.2402 |
| Style | Model | Thread Size | Hex Width | Hex Height | Nut Height | Hardness | Temp. Range | Hex Type | Pkg. Qty. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | M12858.040.0001 | M4 x 0.7 | 7 mm | 5 mm | 5 mm | Rockwell 30 | -58°F to +302°F | Standard Hex Top Lock | 100 | $32.06 | |
| B | M12858.050.0001 | M5 x 0.8 | 8 mm | 5.09375 mm | 5.1 mm | Rockwell 30 | -58°F to +302°F | Standard Hex Top Lock | 100 | $8.41 | |
| A | M12858.060.0001 | M6 x 1 | 10 mm | 6 mm | 6 mm | Rockwell 30 | -58°F to +302°F | Standard Hex Top Lock | 100 | $10.49 | |
| A | M12858.080.0001 | M8 x 1.25 | 13 mm | 8 mm | 8 mm | Rockwell 30 | -58°F to +302°F | Standard Hex Top Lock | 100 | $28.27 | |
| C | M12858.100.0001 | M10 x 1.5 | 17 mm | 10 mm | 10 mm | Rockwell 30 | -58°F to +302°F | Standard Hex Top Lock | 100 | $36.39 | |
| A | M12858.120.0001 | M12 x 1.75 | 19 mm | 12 mm | 12 mm | Rockwell 30 | -58°F to +302°F | Standard Hex Top Lock | 50 | $21.13 | |
| A | M12858.140.0001 | M14 x 2 | 22 mm | 14 mm | 14 mm | Rockwell 30 | -58°F to +302°F | Standard Hex Top Lock | 50 | $77.54 |
