| Item | Centrifugal Pump |
|---|---|
| Amps | 12.8/6.7-6.4A |
| Best Efficiency Flow | 50 GPM |
| Best Efficiency Flow Range @ Head | 22 to 65 GPM @ 35 to 25 ft. |
| Best Efficiency Flow Rate @ Head | 50 GPM @ 30 ft. |
| Best Efficiency Head | 30 ft. |
| Compatible Discharge Pipe Size | 1 1/4" |
| Compatible Intake Pipe Size | 1 1/2" |
| Compatible With Media Type | Water |
| Connection Type | NPT |
| Discharge Type | NPT |
| Drain Plug | All Position |
| Duty Cycle | Continuous |
| For Use With Potable Systems | Yes |
| Frame | 56J |
| Frequency | 60 Hz |
| Grade | Grade 316 |
| Height | 8.1" |
| Housing Material | Cast Iron |
| Hp | 3/4 hp |
| Impeller Dia. | 3 1/8" |
| Impeller Material | Bronze |
| Impeller Type | Closed |
| Inlet Pressure | 30 psi |
| Length | 17 3/5" |
| Max. Flow Rate | 66 GPM |
| Max. Flow Rate @ 20 Ft. | 70 GPM |
| Max. Flow Rate @ 30 Ft. | 55 GPM |
| Max. Flow Rate @ Head | 66 GPM @ 20 ft. |
| Max. Liquid Temp. | 250°F |
| Max. Operating Pressure | 125 psi |
| Max. Solid Dia. | 1/8" |
|---|---|
| Maximum Feet Of Head | 37 ft. |
| Maximum Flow Rate @ 20 Feet Of Head | 70 GPM |
| Media Type | Water |
| Min. Flow Rate | 25 GPM |
| Min. Flow Rate @ Head | 20 GPM @ 34 ft. |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Mounting Orientation | Horizontal, Vertical |
| Overall Height | 8.1" |
| Overall Length | 17.6" |
| Overall Width | 6.7" |
| Phase | 1 |
| Port Rotation | 45 Deg. Increments |
| Priming | Manual |
| Pump Housing Material | Cast Iron |
| Rpm | 3500 RPM |
| Rpm (maximum) | 3500 RPM |
| Seal Material Grade | Grade 316 , Stainless Steel, Buna Elastomer, Carbon, Ceramic |
| Self Priming | Manual |
| Series | 3642 Series |
| Service Factor | 1 |
| Shaft Material | Stainless Steel |
| Shut Off Pressure | 125 psi |
| Solid Diameter (maximum) | 0.13" |
| Specific Gravity | 1 |
| Specific Gravity (maximum) | 1 xg |
| Type | Centrifugal |
| Voltage | 115/230V AC |
| Volute Material | Cast Iron |
| Wetted Material Grade | Grade 316 , Stainless Steel, Bronze, Buna N, Carbon, Ceramic |
| Width | 6 5/7" |
| Height (cm) | 28.19 |
|---|---|
| Length (cm) | 45.97 |
| Width (cm) | 29.21 |
| HS Code | 8413702005 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 19.8 |
| Style | Model | Hp | Phase | Motor Enclosure Design | Voltage | Compatible Intake Pipe Size | Compatible Discharge Pipe Size | Max. Flow Rate @ 20 Ft. | Max. Flow Rate @ 40 Ft. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 4BF1H1K0 | 3 hp | 1 | Open Dripproof | 115/208-230V AC | 3" | 2 1/2" | 172 GPM | 108 GPM | $4,487.61 | |
| B | 2BF50734 | 3/4 hp | 3 | Totally Enclosed Fan Cooled | 208-230/460V AC | 1 1/2" | 1 1/4" | 48 GPM | - | $2,047.50 | |
| B | 2BF40534 | - | 3 | Open Dripproof | 208-230/460V AC | - | - | 48 GPM | - | $1,670.94 | |
| B | 2BF40512 | 1/2 hp | 1 | Open Dripproof | 115/230V AC | 1 1/2" | 1 1/4" | 48 GPM | - | $1,575.09 | |
| B | 2BF21512 | 1 1/2 hp | 1 | Totally Enclosed Fan Cooled | 115/230V AC | 1 1/2" | 1 1/4" | - | 84 GPM | $2,023.21 | |
| B | 2BF21012 | 1 hp | 1 | Totally Enclosed Fan Cooled | - | 1 1/2" | 1 1/4" | - | 66 GPM | $2,023.59 | |
| B | 2BF20734 | 3/4 hp | 3 | Totally Enclosed Fan Cooled | 208-230/460V AC | 1 1/2" | - | 70 GPM | - | $1,957.38 |
