| Item | Centrifugal Pump |
|---|---|
| Amps | 9/4.5A |
| Bearing Type | Ball |
| Best Efficiency Flow Rate @ Head | 60 GPM @ 134 ft. |
| Compatible Discharge Pipe Size | 2" |
| Compatible Intake Pipe Size | 3" |
| Compatible With Media Type | Water |
| Connection Type | NPT |
| Discharge Type | NPT |
| Duty Cycle | Continuous |
| Flow Rate @ 10 Psi | 103 GPM |
| Flow Rate @ 15 Psi | 100 GPM |
| Flow Rate @ 20 Psi | 95 GPM |
| Flow Rate @ 25 Psi | 96 GPM |
| Flow Rate @ 30 Psi | 86 GPM |
| Flow Rate @ 40 Psi | 75 GPM |
| Flow Rate @ 50 Psi | 60 GPM |
| Flow Rate @ 60 Psi | 40 GPM |
| Flow Rate @ 70 Psi | 12 GPM |
| For Use With Potable Systems | No |
| Frequency | 60 Hz |
| Housing Material | Cast Iron |
| Hp | 3 hp |
| Impeller Material | Brass |
| Impeller Type | Closed |
| Intake And Discharge Size | 3", 2" |
| Intake Type | FNPT |
| Manufacturer Warranty Length | 1 yr. |
| Max. Case Pressure | 120 psi |
| Max. Flow Rate @ Psi | 71 GPM |
| Max. Inlet Pressure | 30 psi |
| Max. Media Temp. | 180°F |
| Max. Motor Ambient Temp. | 104°F |
|---|---|
| Max. Pressure Boost | 1.5 GPM |
| Max. Suction Lift | 20 ft. |
| Max. Working Pressure | 86 psi |
| Media Temperature (maximum) | 200°F |
| Media Type | Clear Water |
| Min. Inlet Flow | 2 GPM |
| Min. Motor Ambient Temp. | 40°F |
| Motor Enclosure Design | Open Dripproof |
| Motor Type | JM |
| Mounting Orientation | Horizontal |
| Nema/iec Frame | 145JM |
| No. Of Stages | 2 |
| Overall Height | 9.81" |
| Overall Length | 20.12" |
| Overall Width | 10 1/2" |
| Phase | 3 |
| Plug Or Connector Type | Direct Wire |
| Pump Housing Material | Cast Iron |
| Rpm (maximum) | 3500 RPM |
| Seal Application | Water |
| Seal Material | Buna N, Carbon, Ceramic, Stainless Steel |
| Seal Type | Mechanical |
| Series | 22000 Series |
| Service Factor | 1.15 |
| Shaft Material | Stainless Steel |
| Shut Off Pressure | 85 psi |
| Type | End Suction |
| Voltage | 208-230/460V AC |
| Wetted Material | Carbon Steel, Cast Iron, Silicon Carbide |
| Standards | CSA CERTIFIED, CUS CERTIFIED, UL LISTED |
| Height (cm) | 39.37 |
|---|---|
| Length (cm) | 62.48 |
| Width (cm) | 38.86 |
| HS Code | 8413702040 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 44.145 |
| Style | Model | Hp | Overall Height | Overall Width | Overall Length | Amps | Media Type | Max. Inlet Pressure | Flow Rate @ 10 Psi | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | C22231 | 3 hp | 10.81" | 12.12" | 20.49" | 16.8A | Water | 30 psi | 103 GPM | $5,453.34 | |
| A | C22251 | 5 hp | 10.81" | 12.12" | 22.74" | 26.6A | Water | 30 psi | 146 GPM | $5,814.98 | |
| A | C22253 | 5 hp | 10.81" | 12.12" | 22.74" | 14/7A | Clear Water | 30 psi | 146 GPM | $4,610.42 | |
| A | C22273 | 7 1/2 hp | 10.81" | 12.12" | 22.74" | 21/10.5A | Water | 20 psi | 149 GPM | $4,928.27 |
