| Item | Refrigeration Motor |
|---|---|
| Ambient Temp. | 40°C |
| Amps | 0.9/0.43/1.1/0.49A |
| Application | HVAC/R |
| Bearing Type | Ball |
| Body Dia. | 3 5/16" |
| Bolt Circle Dia. | 2 13/16" |
| Capacitor Required | Yes |
| Drive End Bearing | Ball |
| Duty | Air Over |
| Duty Cycle | Continuous |
| Electrical Type | Permanent Split Capacitor |
| Frame | 3.3 |
| Frame Length | 3.56" |
| Frame Material | Steel |
| Frequency | 50/60 Hz |
| Full Load Amps | 0.9/0.43/1.1/0.49A |
| Hp | 1/12 hp |
| Hz | 60 Hz |
| Includes | Extra Mounting Nuts, Reversing Plug |
| Includes Capacitor | Yes |
| Ins. Class | Class B |
| Insulation Class | Class B |
| Lead Length | 21" |
| Length | 6.86" |
| Length Less Shaft | 3 9/16" |
| Max. Ambient Temp. | 40°C |
| Motor Application | HVAC/R |
| Motor Bearings | Ball |
| Motor Design | Permanent Split Capacitor |
| Motor Enclosure Design | OAO |
| Motor Frame Material | Steel |
| Motor Mounting Type | Ring, Stud |
| Motor Service Factor | 1 |
| Motor Shaft Design | Keyed |
|---|---|
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | Auto |
| Motor Type | Permanent Split Capacitor |
| Mounting Holes | 4 |
| Mounting Stud Location | 4/Both Ends |
| Mounting Type | Extended Studs |
| Nameplate Rpm | 1550/1350 RPM |
| No. Of Mounting Holes | 4 |
| No. Of Poles | 4 |
| No. Of Shafts | 1 |
| No. Of Speeds | 1 |
| No. Of Studs | 4 |
| Opp Drive End Bearing | Ball |
| Output Hp | 1/12 hp |
| Output Kw | 0.06 kW |
| Overall Length | 6 7/8" |
| Permanent Split Capacitor Required | 4 µf, 370V |
| Phase | 1 |
| Rpm | 1350/1550 RPM |
| Service Factor | 1 |
| Shaft Dia. | 0.312" |
| Shaft Extension Size | 3.25" |
| Shaft Length | 3 1/4" |
| Shaft Type | Flat |
| Starting Method | Across The Line |
| Stud Location | Both Ends |
| Stud Pattern | 2" x 2" |
| Stud/base Mtg. Pattern | 2" x 2" |
| Thermal Protection | Automatic , Yes |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 115/208-230V |
| Standards | CSA CERTIFIED, UL RECOGNIZED |
Fasco 9721 HVAC motor is used in heating, ventilation and air conditioning (HVAC) systems. It is used to drive fans, blowers or other air-moving equipment, ensuring efficient air circulation and temperature control in commercial settings.
| Height (cm) | 14.99 |
|---|---|
| Length (cm) | 22.61 |
| Width (cm) | 15.24 |
| Country Of Origin | CN |
|---|---|
| Weight (kg) | 2.0025 |
It offers a ball bearing motor for enhancing durability and reducing friction for smoother & longer-lasting operation.
The motor offers Class B insulation to ensure that the motor can handle the heat generated during operation without posing a risk of electrical failure or fire.
Yes, it includes extra mounting nuts for convenience during installation & comes with a reversing plug, allowing for easy and quick adjustment of the motor's rotation direction.
