| Item | DC Gearmotor |
|---|---|
| Application | Dvd Kiosks, Ice Dispensing, Mail Sorting, Ticket Dispensing, Vending Machines |
| Bearing Type | Ball On Case, Ball On Motor |
| Brush Type | Externally Replaceable |
| Features | These Dc Gearmotors Can Be Mounted In Small Spaces And In Multiple Positions |
| Finish | Powder Coat |
| Full Load Amps | 2.4A |
| Gear Case | Die Cast Aluminum |
| Gear Case Material | Die Cast Aluminum |
| Gear Ratio | 36:1 |
| Gear Type | Helical, Worm |
| Housing Material | Aluminum |
| Housing Material Finish | Powder Coated |
| Input Hp | 1/8 hp |
| Keyway Depth | 3/16" |
| Keyway Length | 1 1/8" |
| Keyway Size | 3/16" x 1 1/8" |
| Keyway Type | Square |
| Keyway Width | 3/16" |
| Lubrication | Grease Filled |
| Max. Ambient Temp. | 40°C |
| Maximum Torque | 56.2 lbs.-in. |
| Motor Enclosure | Totally Enclosed Non Ventilated |
| Motor Frame | Non Standard |
| Motor Insulation Class | Class B |
| Motor Type | Permanent Magnet DC |
|---|---|
| Mounting | All Position |
| Mounting Orientation | Any Angle |
| Nameplate Rpm | 90.3 RPM |
| No Load Rpm | 90.3 RPM |
| Operating Voltage | 24V DC |
| Output Shaft Diameter | 5/8" |
| Overall Height | 4.65" |
| Overall Length | 10.24" |
| Overall Width | 5.16" |
| Overhung Load | 157.3 lbs. |
| Overhung Load Capacity | 157 lbs.-ft. |
| Replaceable Motor Brushes | Yes |
| Reversible Shaft Output | Yes |
| Rotation | CW/CCW |
| Rpm Range | 76-100 RPM |
| Seal Type | Lip |
| Seals | Lip Type |
| Service Factor | 1 |
| Shaft | Single Output |
| Shaft Orientation | Right Angle |
| Thermal Protection | No |
| Voltage | 24V DC |
| Standards | CSA CERTIFIED, UL RECOGNIZED |
| Height (cm) | 11.81 |
|---|---|
| Length (cm) | 29.21 |
| Width (cm) | 13.11 |
| HS Code | 8501314000 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 5.6025 |
