| Item | Whole House Fan Premium Ceiling Shutter / Ceiling Shutter |
|---|---|
| Action | Single Acting |
| Air Flow Direction | Horizontal |
| Blade Material | Aluminum |
| Blade Material Thickness | 26 ga. |
| Blade Seal Material | Felt |
| Bushing Material | Stainless Steel |
| Closure Type | Spring |
| Color | White |
| Counterbalanced | Yes |
| Damper Finish | Baked Enamel |
| Fits Fan Dia. | 36" |
| Flange Type | Front Flange |
| Flange Width | 1 3/8" |
| For Use With | 36 In Whole House Fans |
| Frame Depth | 1 5/8" |
| Frame Material | Aluminum |
| Frame Material Thickness | 0.1 ga. |
| Free Area | 8.1 sq. ft. |
| Length | 35" |
| Max. Velocity | 2250 FPM |
| Maximum Air Velocity | 2250 FPM |
| Maximum Pressure | 1 in. wc |
| Mounting Hole Di. | 1/4" |
| Mounting Hole Diameter | 1/4" |
| Mounting Hole Size | 0.188" |
|---|---|
| Mounting Location | Ceiling, Wall |
| Mounting Position | Horizontal, Vertical |
| Mounting Style | Flush Mount |
| Number Of Panels | 1 |
| Open Depth | 5" |
| Opening Length | 33" |
| Opening Required | 30" x 30" |
| Opening Type | Spring |
| Opening Width | 38" |
| Overall Height | 35" |
| Overall Length | 40" |
| Overall Width | 35" |
| Rough Opening Length | 38" |
| Rough Opening Shape | Rectangular |
| Rough Opening Width | 33" |
| Shutter Mounting Location | Ceiling |
| Shutter Mounting Position | Horizontal |
| Shutter Opening Required | 33" x 38" |
| Single Acting/double Acting | Single Acting |
| Switch Action | NC |
| Tie-rod Material | Galvanized Steel Frame And Tie Rods |
| Type | Gravity Operated Single Panel |
| Width | 40" |
| Height (cm) | 104.9 |
|---|---|
| Length (cm) | 90.68 |
| Width (cm) | 5.33 |
| HS Code | 7610900080 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 6.408 |
| Style | Model | Mounting Location | Flange Width | Frame Depth | Max. Velocity | Mounting Position | Fits Fan Dia. | Opening Width | Opening Length | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 3C242 | Ceiling | 1 3/8" | 1 5/8" | 2250 FPM | Horizontal, Vertical | 42" | 42" | 42" | $501.51 | |
| B | 3HHR2 | Ceiling | 1 3/8" | 1 5/8" | 1500 FPM | Horizontal, Vertical | 24" | 24" | 24" | $205.24 | |
| B | 3HHR3 | Ceiling | 1 3/8" | 1 5/8" | 1500 FPM | Horizontal, Vertical | 30" | 30" | 30" | $196.46 | |
| B | 3HHR4 | Ceiling | 1 3/8" | 1 5/8" | 1500 FPM | Horizontal, Vertical | 36" | 34" | 34" | $212.54 | |
| C | 4HA10 | Ceiling | 1 5/8" | 1 3/8" | 1500 FPM | Horizontal | 24" | 27.7" | 70 3/4" | $190.64 | |
| C | 4HA11 | - | 1 5/8" | 1 5/8" | 1500 FPM | Horizontal | 30" | 33.9" | 70 3/4" | $208.70 | |
| C | 4HA12 | Ceiling | 1 5/8" | 1 3/8" | 1500 FPM | Horizontal | 36" | 34" | 35 3/4" | $243.96 |
