CONDOR USA SK-R3/10 Thermal Overload, 6.3 to 10 A, 3-Phase, 600 VAC

What is Condor SK-R3/10 used for?

This thermal overload unit protects the motor in case of phase failure or overload.

What causes thermal overload?

Thermal overload causes include a large change in load, misalignment, a broken drive gear, or improper motor drive settings. Power problems also may cause an overload condition.

What is the phase configuration of Condor SK-R3/10 thermal overload block?

3 phase.

What causes thermal overload?

Thermal overload causes include a large change in load, misalignment, a broken drive gear, or improper motor drive settings. Power problems also may cause an overload condition.

How does a thermal overload block work?

• A thermal overload block works by sensing the temperature rise due to current flow and tripping the circuit breaker if the temperature exceeds a certain limit.
• The temperature is proportional to the current, so the overload block acts as a thermal switch that opens when the current exceeds a certain value.

What safety precautions should I take when using Condor SK-R3/10 thermal overload block?

• Read the manual thoroughly to understand proper usage guidelines and limitations.
• Ensure correct installation according to manufacturer specifications and safety codes.
• Avoid exceeding the maximum amp rating to prevent overheating and damage.
• Regularly inspect for signs of damage, wear or corrosion, replacing worn components promptly.
• Perform routine maintenance checks on associated equipment for optimal functionality.
• Implement emergency shutdown procedures in case of abnormal conditions or malfunctions.
• Provide proper training to personnel for safe operation and hazard awareness.

Does Raptor Supplies offer a similar thermal overload block with a higher current rating?

Yes, you can check out Condor SK-3 thermal overload block with a current rating of 30
