| Item | IEC Frame AC Motor |
|---|---|
| Ac/dc | AC |
| Ambient Temp. | 40°C |
| Amps | 3.2-3/1.5A |
| Amps @ 208v | 3.6A |
| Base Type | Not Applicable |
| Break-down Torque | 10 lbs.-ft. |
| Class | Stock |
| Code | K |
| Conduit Box Position | F2 |
| Design Code | B |
| Enclosure Design | TEFC |
| Frame | D80C |
| Frame Size | D80C |
| Frequency | 60 Hz |
| Full Load Amps | 3.2-3/1.5A |
| Full Load Torque | 2.25 lbs.-ft. |
| Hp | 1/26 hp |
| Insulation Class | Class B |
| Ip Rating | IP54 |
| Lead | 9#18 |
| Line-line Res. @ 25° C | 17.68 ohms A Ph/0 ohms B Ph |
| Locked-rotor Torque | 8.8 lbs.-ft. |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Mounting Type | Rigid Base |
| Multiplier | K |
|---|---|
| Nameplate Rpm | 1725 RPM |
| No Load Amps | 1.2A |
| No. Of Motor Leads | 9 |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 75.5% |
| Output Kw | 0.56 kW |
| Phase | 3 |
| Power Factor | 60 |
| Proprietary | No |
| Pull-up Torque | 8.5 lbs.-ft. |
| Revision | T |
| Rpm | 1700-1800 RPM |
| Service Factor | 1.25 |
| Shaft Rotation | Reversible |
| Start Configuration | DOL |
| Starting Amps | 10A |
| Temp. Rise @ Rated Load | 74°C |
| Temp. Rise @ S. F. Load | 91°C |
| Type | 3420M |
| Voltage | 208-230/460V |
| Wire Size | 18 AWG |
| Base Indicator | None |
| Xp Class And Group | None |
| Height (cm) | 23.81 |
|---|---|
| Length (cm) | 35.09 |
| Width (cm) | 27.47 |
| HS Code | 85015100 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 11.7 |
| Style | Model | Voltage | Hp | Service Factor | Nameplate Rpm | Mounting Type | Motor Type | Frame | Insulation Class | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | EMVM3546C | 230/460V | 3/4 hp | 1.15 | 1760 RPM | B14 | 3520M | D80C | Class F | $1,314.76 | |
| A | EMVM3558C | 208-230/460V | 1 1/2 hp | 1.15 | 1755 RPM | B14 | 3528M | D90LC | Class F | $1,401.77 | |
| A | EMVM3559C | 208-230/460V | 11/5 hp | 1.15 | 3450 RPM | B14 | 3532M | D90SC, LC | Class F | $1,565.29 | |
| A | EMVM3611C | 208-230/460V | 11/5 hp | 1.15 | 1760 RPM | B14 | 3632M | D100C | Class F | $1,684.81 | |
| A | EMVM3613C | 208-230/460V | 37/10 hp | 1.15 | 3450 RPM | B14 | 3634M | D100LC | Class F | $2,062.50 | |
| A | EMVM3615C | 208-230/460V | 37/10 hp | 1.15 | 1750 RPM | B14 | 3642M | D112MC | Class F | $1,922.90 | |
| B | MVM3458C | 230/460V | 1/4 hp | 1.35 | - | Rigid Base | - | D71C | Class B | $800.33 |
