| Item | General Purpose Motor |
|---|---|
| Ambient Temp. | 40°C |
| Amps @ Voltage | 156A @ 415V, 160A @ 400V, 93.2A @ 690V |
| Auxillary Box | Top |
| Duty | S1 |
| Efficiency | 94.7% |
| Efficiency @ 100% Load | 94.7% |
| Efficiency @ 50% Load | 94.2% |
| Efficiency @ 75% Load | 94.8% |
| Enclosure Design | TEFC |
| Frame | 280 |
| Frame Material | Cast Iron |
| Frequency | 50 Hz |
| High Voltage Full Load Amps | 93.2A |
| Hp | 90 hp |
| Insulation Class | Class F |
| Ip Rating | IP55 |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Mounting Type | Foot Mounted |
|---|---|
| Nameplate Rpm | 1483/1484 RPM |
| Nema/iec | IEC |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Output @ Frequency | 90 kW @ 50 Hz |
| Output Kw | 90 kW |
| Phase | 3 |
| Power Factor | 0.85 |
| Product Family | Process Performance |
| Rotor Inertia | 0.00015 lbs.-sq. ft. |
| Rpm | 1483/1484 RPM |
| Service Factor | 1 |
| Shaft Dia. | 80 mm |
| Synchronous Rpm @ Frequency | 1500 RPM @ 50 Hz |
| Voltage | 400/415/690V |
| Voltage @ Frequency | 400V @ 50 Hz, 415V @ 50 Hz, 690V @ 50 Hz |
| Height (cm) | 129.54 |
|---|---|
| Length (cm) | 124.46 |
| Width (cm) | 83.82 |
| HS Code | 85015381 |
|---|---|
| Country Of Origin | FI |
| Weight (kg) | 746.55 |
