| Item | General Purpose Motor |
|---|---|
| Ac/dc | AC |
| Ambient Temp. | 40°C |
| Amps | 136/68A |
| Base Indicator | Rigid |
| Base Type | Rigid Base |
| Break-down Torque | 304 lbs.-ft. |
| Conduit Box Material | Steel |
| Conduit Box Position | F1 |
| Design Code | A |
| Duty | Continuous |
| Enclosure Design | OPSB |
| Frame | 326TS |
| Frame Material | Steel |
| Frame Size | 326TS |
| Frequency | 60 Hz |
| Full Load Amps | 136/68A |
| Full Load Torque | 88.9 lbs.-ft. |
| Grease Type | Polyrex EM |
| Hp | 60 hp |
| Insulation Class | Class F |
| Inverter Code | Inverter Ready |
| Kva Code | G |
| Lead | 9#6 |
| Line-line Res. @ 25° C | 0.09668 ohms A Ph/0 ohms B Ph |
| Locked-rotor Torque | 128 lbs.-ft. |
| Lubrication | Polyrex EM |
| Motor Enclosure Design | Open Slotted Band |
| Motor Type | Three Phase |
| Mounting Type | Foot Mounted |
|---|---|
| Multiplier | L1 |
| Nameplate Rpm | 3540 RPM |
| Nema/iec | NEMA |
| No Load Amps | 17.7A |
| No. Of Motor Leads | 9 |
| No. Of Poles | 2 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 93.6% |
| Overall Length | 25.19" |
| Phase | 3 |
| Power Factor | 89 |
| Proprietary | No |
| Pull-up Torque | 91.4 lbs.-ft. |
| Pulley Face Code | Standard |
| Revision | L |
| Rpm | 3400-3600 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 1 7/8" |
| Shaft Ground Indicator | No Shaft Grounding |
| Shaft Rotation | Reversible |
| Start Configuration | DOL |
| Starting Amps | 443A |
| Synchronous Rpm | 3600 RPM |
| Temp. Rise @ Rated Load | 35°C |
| Temp. Rise @ S. F. Load | 43°C |
| Type | 4250M |
| Voltage | 230/460V |
| Wire Size | 6 AWG |
| Height (cm) | 58.42 |
|---|---|
| Length (cm) | 87.63 |
| Width (cm) | 67.31 |
| HS Code | 85015230 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 205.6504 |
