| Item | Transformer |
|---|---|
| Anfc Taps | 2 |
| Bnfc Taps | 4 |
| Construction | Ventilated |
| Depth | 41 1/2" |
| Dimensions | 41.5" x 45.6" x 57.8" |
| Efficiency | 99.14% |
| Frequency | 60 Hz |
| Height | 57.8" |
| Kva Rating | 500 kVA |
| Length | 41.5" |
| Material | Ventilated |
| Max Temperature Rise | 150°C |
|---|---|
| Max. Temp. | 150°C |
| Mounting Type | Floor |
| Nema Rating | Nema 3R |
| Primary Voltage | 480V |
| Secondary Voltage | 240 120V , 240/120V , 240V |
| Taps % Steps | 2.5% |
| Ul Insulation Class | 220°C |
| Ul Standard | UL 1561 |
| Va Rating - Transformer | 500 kVA |
| Width | 45.6" |
| Winding Material | Aluminum |
| Height (cm) | 146.81 |
|---|---|
| Length (cm) | 105.41 |
| Width (cm) | 115.82 |
| Country Of Origin | CN |
|---|---|
| Weight (kg) | 1203.75 |
