| Item | Resin Splice Kit |
|---|---|
| Barrel Length | Not Applicable |
| Body Material | Polypropylene |
| Color | Black |
| Container Type | Closed Mixing Pouch |
| For Max. Cable Od | 2 1/4" |
| Includes Resin | Yes |
| Material | EPDM Rubber, Resin |
| Max. Cable Dia. | 1 1/4" |
| Max. Temp. | 194°F |
| Max. Voltage | 1000V |
| Max. Wire Size | 10 AWG |
| Min. Wire Size | 22 AWG |
| Number Of Splices | 1 |
|---|---|
| Overall Length | 20.3" |
| Resin Material | Resin |
| Rohs Compliant | Yes |
| Screw Finish | Not Applicable |
| Screw Material | Not Applicable |
| Seam Style | Butted |
| Standard Length | 20 5/16" |
| Stud Size | Not Applicable |
| Temp. Range | +194°F to +266°F |
| Tensile Strength | 600 psi |
| Termination Style | Splice |
| Voltage Rating | 1000V |
| Height (cm) | 19.81 |
|---|---|
| Length (cm) | 51.56 |
| Width (cm) | 20.57 |
| HS Code | 3909505000 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 4.005 |
| Style | Model | Overall Length | Standard Length | Max. Cable Dia. | Termination Style | Max. Wire Size | Min. Wire Size | Max. Voltage | Color | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 72-N1 | 7.1" | 7 1/8" | 1/4" | Splice | 10 AWG | 22 AWG | 1000V | Black | $163.71 | |
| A | 72-N2 | 10 3/5" | 10 7/16" | 1/2" | Splice | 10 AWG | 22 AWG | 1000V | Black | $173.53 | |
| B | 72-N3 | 15 2/5" | 15 7/16" | 5/8" | Splice | 10 AWG | 22 AWG | 1000V | Black | $300.74 | |
| B | 72-N4 | 15 3/5" | 15 5/8" | 1" | Splice | 10 AWG | 22 AWG | 1000V | Black | $572.97 | |
| B | 72-N6 | 25" | 25" | 1 1/4" | Splice | 10 AWG | 22 AWG | 1000V | Black | $1,658.60 |
