TRICO 30220 Constant Level Oiler, 16 oz. Capacity, 4-1/8 Inch Size, SS, Glass Reservoir

Item: AK7FJC
Model: 30220
Check Availability
In Stock.

Get it by Monday, Feb 9

£9.99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates

We deliver to your doorstep under DAP terms. Customs clearance is for your account

$236.74 /unit (ex. VAT)
Add To Cart
Request Quote

Unlock 30-day payment terms

Business customers can apply for Net 30
No fees, No interest, Fast approval.

Payment

Delivery

Specifications

Item Constant Level Oiler
Capacity 16 oz.
Connection Size 1/4"
Material Stainless Steel
Max. Operating Temp. 250°F
O-ring Viton
Oil Level Range 9/32" to 1"
Reservoir Material Glass
Width 4 1/8"

Shipping Information

Height (cm) 17.14
Length (cm) 10.46
Width (cm) 10.46
HS Code 8413919520
Country Of Origin US
Weight (kg) 0.81

Working Mechanism

  • Trico Opto-Matic oiler has a control point that should align with the oil level of the equipment.
  • As oil is depleted in the equipment, the fluid seal (on the spout) breaks.
  • During this, air flows from the air vent to the oil reservoir.
  • This releases the fluid from the reservoir, allowing it to flow into the equipment until the re-establishment of the liquid seal.

Compatible Accessories

  • Trico Opto Laser Levels: These easy-to-install units act as inspection devices for indicating the accurate setting of the level of oil in Opto-Matic oilers.

Standards and Approvals

  • ISO 9001:2015
  • ISO / IEC 17025:2017
  • ASTM

Documentation

Frequently Asked Questions

At what temperatures does this Opto-Matic oiler work?

It can work at a maximum temperature of 250 degrees Fahrenheit.

How is Opto-Matic constant oiler installed?

  • Before installing, shaft rotation direction must be determined.
  • Install the oiler on the side of the equipment facing the direction of shaft rotation to prevent misfeeding of the oiler.
  • Determine the proper oil level either indicated by an arrow or manually marked using a marking device.
  • Loosen set screw and remove reservoir assembly.
  • Check that all connecting hardware is free from contamination.
  • Connect lower casting to the bearing chamber and verify that the casting is parallel with the desired oil level.
  • Measure the distance between the oiler & casting edge and set the oiler level adjuster i.e. Opto laser level tool.
  • Thread the upper adjuster arm to the needed level and once the correct level is obtained, lock the lower level adjuster arm against the upper arm.
  • Fill the equipment bearing chamber through the lower casting and use a funnel to fill the reservoir assembly.
  • Tighten the set screw and start the equipment.
