| Item | Pendent Contact Block |
|---|---|
| Ac Contact Rating | 1.2A @ 600V, 3A @ 240V |
| Action Type | Momentary |
| Ambient Air Temp. For Operation | -13°F to +158°F |
| Ambient Air Temp. For Storage | -40°F to +158°F |
| Color | Black |
| Compatible Operator | Pilot Light, Push Button |
| Compatible With Series | Xaca, Xb4, Xb5 |
| Component Name | ZB2 |
| Component Type | Contact Block |
| Connections Terminals | Screw Clamps Terminals, 1 x 2.5 mm sq. With Or Without Cable End, Screw Clamps Terminals, 2 x 1.5 mm sq. With Or Without Cable End |
| Contact Block Application | Single Speed |
| Contact Block Type | Single |
| Contact Form | 1NC Slow Break |
| Contact Operation | Slow Break |
| Contact Rating | 10A @ 600V AC |
| Contact Type And Composition | 1 NC |
| Conventional Enclosed Thermal Current | 10A |
| Dc Contact Rating | 0.1A @ 600V, 0.27A @ 250V |
| Electrical Circuit Type | Control Circuit |
| Electrical Shock Protection Class | Class II |
| Includes Mounting Block | No Mounting Block Included |
| Manufacturer Warranty Length | 18 Months |
|---|---|
| Maximum Resistance Across Terminals | 25 M ohms |
| Mechanical Durability | 1000000 Cycles |
| Mounting Location | Front |
| Mounting Of Block | Front Mounting |
| Nema Contact Rating Designation | A600/Q150DN |
| Operating Force | 13N to 15N |
| Operator Type | Spring Return |
| Panel Mounting Hole Diameter | 22 mm |
| Product Compatibility | XACA, XB4, XB5 |
| Rated Impulse Withstand Voltage | 6 kV |
| Rated Insulation Voltage | 600V |
| Rated Operational Power In W | 40 W DC-13 1000000 Cycles 3600 cyc/h 120V 0.5 IEC 60947-5-1, 48 W DC-13 1000000 cycles 3600 cyc/h 48V 0.5 IEC 60947-5-1, 65 W DC-13 1000000 cycles 3600 cyc/h 24V 0.5 IEC 60947-5-1 |
| Returnability | Yes |
| Short-circuit Protection | 10A fuse protection cartridge gG |
| Switch Action | Momentary |
| Terminal Connection Type | Screw Clamp Terminals |
| Type Of Operator | Momentary |
| Vibration Resistance | 15 gn (10-500 Hz) Conforming to IEC 60068-2-6 |
| standard | CSA C22.2 NO.14, EN/IEC 60204-32, EN/IEC 60947-5-1, UL 508 |
| Warranty | 18 Months |
Square D ZB2BE102 contact block is suitable for use with circuit breakers, relays and switches in electrical circuits for instrumentation and power management operations.
| Height (cm) | 3.99 |
|---|---|
| Length (cm) | 10.01 |
| Width (cm) | 14 |
| HS Code | 8536904000 |
|---|---|
| Country Of Origin | MX |
| Weight (kg) | 0.0149 |
It is a single-pole contact block.
It can offer a maximum resistance of 25 Mega Ohm to the terminals.
Yes, safety is paramount when working with electrical components. Always follow proper lockout / tagout procedures when servicing contact blocks to prevent accidental energisation.
Keep the temperature between -25 to 70 degrees C while operating this contact block. However, this Square D contact block can withstand temperatures as low as -40 degrees Celsius when not in use.
| Style | Model | Contact Rating | Nema Contact Rating Designation | Action Type | Color | Terminal Connection Type | Contact Form | Type Of Operator | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|
| A | XENG1191 | 10A @ 600V AC/DC | A600/Q600 | Momentary/Make Before Break | Black | Screw Clamp Terminals | - | Momentary | $79.60 | |
| B | ZB2BE101 | 10A @ 600V AC | A600/Q150DN | Momentary | Black | Screw Clamp Terminals | - | Momentary | $30.53 |
