| Item | Disc Spring |
|---|---|
| Calculated Load @ Flat | 4464N |
| Compatible Rod Size | 10.203125 mm |
| Deflection @ Load | 0.37 mm |
| Disc Type | Standard Disc Spring |
| Finish | Oil |
| Inside Diameter | 10.2 mm |
| Load @ Deflection | 2654N |
| Material | Carbon Steel |
| Max. Outside Dia. | 0.787" |
|---|---|
| Min. Inside Dia. | 0.402" |
| Outside Diameter | 20 mm |
| Overall Height | 1.7 mm |
| System Of Measurement | Metric |
| Thickness | 1.25 mm |
| Type | Metric Disc Spring |
| Standards | C1074-1075 |
| Height (cm) | 1.78 |
|---|---|
| Length (cm) | 2.29 |
| Width (cm) | 2.29 |
| HS Code | 7318210090 |
|---|---|
| Weight (kg) | 0.09 |
| Style | Model | Overall Height | Thickness | Calculated Load @ Flat | Material | Finish | Load @ Deflection | Pkg. Qty. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|
| A | BD063-350 | 4.9 mm | 3.5 mm | 25056N | Carbon Steel | Oil | 15774N | 10 | $197.80 | |
| A | BD070-200-0255 | 4.5 mm | 2 mm | 7998N | Carbon Steel | Oil | 4756N | 10 | $149.64 | |
| A | BD070-250-0305 | 4.9 mm | 2.5 mm | 14473N | Carbon Steel | Oil | 8606N | 10 | $142.84 | |
| A | BD070-300 | 5.1 mm | 3 mm | 22148N | Carbon Steel | Oil | 13171N | 10 | $150.74 | |
| A | BD070-300-0305 | 5.1 mm | 3 mm | 20594N | Carbon Steel | Oil | 12246N | 10 | $150.74 | |
| A | BD070-400 | 5.8 mm | 4 mm | 39938N | Carbon Steel | Oil | 25143N | 10 | $191.70 | |
| A | BD020-150 | 1.8 mm | 1.5 mm | 4545N | Carbon Steel | Oil | 2703N | 15 | $58.67 |
