| Item | Disc Spring |
|---|---|
| Calculated Load @ Flat | 10057 lbf. |
| Compatible Hole Diameter | 3 1/2" |
| Compatible Rod Size | 1 1/16" |
| Disc Type | Belleville Spring |
| Finish | Plain |
| For Hole Size | 3 1/2" |
| For Rod Size | 1.063" |
| Inside Diameter | 1.06" |
| Load @ Deflection | 6463 lbs. |
| Material | Carbon Steel |
|---|---|
| Max. Outside Dia. | 3 1/2" |
| Min. Inside Dia. | 1.063" |
| Outside Diameter | 3.5" |
| Overall Height | 7/25" |
| System Of Measurement | Imperial |
| Thickness | 0.219" |
| Type | Belleville |
| Standards | UNS G61500 |
| Height (cm) | 6.6 |
|---|---|
| Length (cm) | 9.14 |
| Width (cm) | 9.14 |
| HS Code | 7318210090 |
|---|---|
| Weight (kg) | 1.08 |
| Style | Model | Overall Height | Calculated Load @ Flat | Thickness | Load @ Deflection | For Hole Size | Material | Finish | Pkg. Qty. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | B2250156 | 1/5" | 6601 lbf. | 0.156" | 4257 lbs. | 2 1/4" | Carbon Steel | Plain | 10 | $222.44 | |
| A | B2375156 | 0.21" | 6278 lbf. | 0.156" | 4051 lbs. | 2 3/8" | Carbon Steel | Plain | 10 | $326.27 | |
| A | B27501320 | 1/5" | 4243 lbf. | 0.132" | 2752 lbs. | - | Carbon Steel | Plain | 10 | $193.97 | |
| A | B2750187 | 6/25" | 7893 lbf. | 0.187" | 5082 lbs. | - | Carbon Steel | Plain | 10 | $247.61 | |
| A | B2750219 | 0.26" | 11398 lbf. | 0.219" | 7319 lbs. | - | Carbon Steel | Plain | 10 | $211.14 | |
| A | B30001430 | 0.21" | 4970 lbf. | 0.143" | 3216 lbs. | - | Carbon Steel | Plain | 10 | $198.93 | |
| A | B3500312 | 0.35" | 15240 lbf. | 0.312" | 9987 lbs. | 3 1/2" | Carbon Steel | Plain | 10 | $331.10 |
