| Item | Repair Clamp |
|---|---|
| Bolt Dia. | 5/8" |
| Bolt Length | 6 7/8" |
| Bolt Material | Steel |
| Clamp Material | Stainless Steel |
| Clamp Material Grade | Grade 304 |
| Dimensions | 5/8" x 6 7/8" |
| For Fluid Type | Acids, Aliphatic Hydrocarbon Fluids, Alkalies, Chemicals, Natural Gas, Oils, Water |
| For Maximum Copper Tube Size | 10" |
| For Maximum Outside Diameter | 117/16" |
| For Minimum Copper Tube Size | Not Applicable |
| For Minimum Outside Diameter | 11 1/16" |
| Full Circle | Yes |
| Gasket Coverage | Full Coverage |
| Gasket Material | Nitrile Rubber |
| Grade | 304 |
| Length | 12 1/2" |
| Lug Material | Iron |
| Material | Stainless Steel |
|---|---|
| Max. Pressure | 300 psi |
| Maximum Operating Pressure | 300 psi |
| Maximum Operating Temperature | 180°F |
| Maximum Vacuum Pressure | 10 psi |
| Minimum Operating Temperature | -20°F |
| Number Of Bolts | 5 |
| Nut Material | Steel |
| Outlet Connection | Yes |
| Outlet Connection Type | IP |
| Outlet Pipe Size | 1" |
| Outside Dia. | 11.04" to 11.44" |
| Overall Length | 12.5" |
| Pipe Size | 10" |
| Product Type | Full Coverage Clamp With Tap |
| Tap Connection | 1" |
| Type | Full Circle |
| Standards | ANSI A21.11, ASTM A536 |
| Height (cm) | 34.29 |
|---|---|
| Length (cm) | 41.15 |
| Width (cm) | 33.53 |
| HS Code | 7307290090 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 10.1475 |
| Style | Model | Gasket Material | Bolt Material | For Minimum Outside Diameter | For Maximum Outside Diameter | For Pipe Size | Number Of Bolts | Outlet Connection | For Maximum Copper Tube Size | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 238111012007 CC | Nitrile | Carbon Steel | - | - | - | 5 | CC | 10" | $663.04 | |
| A | 238111012009 CC | Nitrile | Carbon Steel | - | - | - | 5 | CC | 10" | $634.58 | |
| A | 238132007006 IP | Nitrile Rubber | Steel | 13 1/8" | 13 1/2" | - | 3 | Yes | 12" | $542.89 | |
| A | 238132007007 CC | Nitrile | Carbon Steel | - | - | - | 3 | CC | 12" | $507.37 | |
| A | 238132007008 IP | Nitrile Rubber | Steel | 13 1/8" | 13 1/2" | - | 3 | Yes | 12" | $507.37 | |
| A | 238132007009 CC | Nitrile Rubber | Steel | 13 1/8" | 13 1/2" | - | 3 | Yes | 12" | $507.37 | |
| A | 238132012006 IP | Nitrile Rubber | Steel | 13 1/8" | 13 1/2" | 12" | 5 | Yes | 12" | $745.25 |
