| Item | Solenoid Air Control Valve |
|---|---|
| Actuator Type | Double Solenoid |
| Ambient Temp. Range | +14°F to +122°F |
| Body Features | Single |
| Body Material | Aluminum |
| Body Style | Base Mounted |
| Center Position | Closed |
| Cfm | 0.29 CFM |
| Coefficient Of Volume | 0.3 |
| Electrical Connection | Plug Connector With Lead Wire |
| Electrical Connection Type | Plug In |
| Exhaust Port Connection Gender | Female |
| Flow Rate - Maximum | 0.29 CFM |
| For Media | Air |
| Includes Mounting Hardware | Hardware Included |
| Includes Solenoid Coil | Yes |
| Inlet Port Connection Gender | Female |
| Lubrication | Lubrication Not Required |
| Number Of Ports | 5 |
| Number Of Positions | 3 |
| Number Of Ways | 5 |
| Operating Pressure - Maximum | 101 psi |
| Operating Pressure - Minimum | 15 psi |
| Operating Temperature - Maximum | 122°F |
|---|---|
| Operating Temperature - Minimum | 14°F |
| Overall Height | 4 5/8" |
| Overall Length | 2 3/32" |
| Overall Width | 1 1/2" |
| Override | Non-Locking |
| Pilot Port Connection Gender | Female |
| Pilot Pressure | 30 psi |
| Pilot Type | Internal Pilot |
| Power Consumption | 0.4 W |
| Pressure | 30 psi to 100 psi |
| Pressure Rating | 30 psi to 100 psi |
| Product Type | Solenoid Air Control Valve |
| Response Time | 15 ms |
| Return Action | Spring Return |
| Seal Material | Rubber |
| Series | SY3000 Series |
| Shifting Technology | Solenoid |
| Spool Material | Aluminum |
| Standards | Rohs Compliant |
| Vacuum Rating | Not Vacuum Operable |
| Valve Type | Spool |
| Voltage | 24V DC |
| Height (cm) | 12.7 |
|---|---|
| Length (cm) | 3.81 |
| Width (cm) | 1.9 |
| HS Code | 8481200060 |
|---|---|
| Weight (kg) | 0.0675 |
| Style | Model | Voltage | Coefficient Of Volume | Overall Height | Overall Width | Overall Length | Center Position | Pressure | Electrical Connection | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | VQ2301-51 | 24V DC | 0.6 | 3/4" | 2" | 5" | Closed | 30 psi to 100 psi | Plug In | $225.30 | |
| A | VQ2401-51 | 24V DC | 0.49 | 3/4" | 2" | 5" | Open | 30 psi to 100 psi | Plug In | $221.66 | |
| B | SY3440-5LZ | 24V DC | 0.3 | 4 5/8" | 1 1/2" | 2 3/32" | Exhaust | 30 psi to 100 psi | Plug Connector With Lead Wire | $211.51 | |
| B | SY3540-5LZ | 24V DC | 0.3 | 4 5/8" | 1 1/2" | 2 3/32" | Pressure | 30 psi to 100 psi | Plug Connector With Lead Wire | $209.16 | |
| C | SY5340-5LZ | 24V DC | 0.47 | 5 1/2" | 1 1/2" | 2" | - | 30 psi to 100 psi | Plug Connector With Lead Wire | $189.70 | |
| C | SY5440-5LZ | 24V DC | 0.72 | 5 1/2" | 1 1/2" | 2" | Exhaust | 30 psi to 100 psi | Plug Connector With Lead Wire | $219.94 | |
| C | SY5540-5LZ | 24V DC | 0.48 | 5 1/2" | 1 1/2" | 2" | Pressure | 30 psi to 100 psi | Plug Connector With Lead Wire | $216.39 |
