| Item | Gate Valve |
|---|---|
| Ansi Flange Class | Class 150 |
| Body Material | 316 Stainless Steel |
| Bonnet Material | Stainless Steel |
| Bonnet Style | Bolted |
| Class | Class 150 |
| Connection Size - Side 1 | 1" |
| Connection Size - Side 2 | 1" |
| Connection Type | Class 150 Flange |
| Connection Type - Side 1 | Flange |
| Connection Type - Side 2 | Flange |
| For Media | Steam, Water |
| Handle Diameter | 4.72" |
| Handle Height | 9.21" |
| Handle Material | Ductile Iron |
| Handle Type | Wheel |
| Inlet To Outlet Length | 5" |
| Max. Fluid Temp. | 450°F |
| Max. Pressure (cwp) | 275 psi |
| Max. Steam Pressure | 150 psi |
| Max. Water Pressure | 275 psi |
|---|---|
| Media Temp. Range | -20°F to +450°F |
| Media Temperature Range | -20°F to +450°F |
| Nominal Valve Size | 1" |
| Number Of Flange Bolt Holes | 4 |
| Operating Temperature - Maximum | 450°F |
| Operating Temperature - Minimum | -20°F |
| Overall Length | 5" |
| Pipe Size | 1" |
| Seal Material | RPTFE |
| Seat Material | Stainless Steel |
| Standards | Api 598, Api 603, Asme B16.34 |
| Stem Grade | Grade 316 |
| Stem Material | 316 Stainless Steel |
| Stem Type | Rising |
| Top Of Handle To Inlet Center | 9" |
| Valve Series | 35 |
| Valve Stem Type | Rising |
| Wedge Material | CF8M Stainless Steel |
| Wedge Style | Flexible |
| Height (cm) | 11.68 |
|---|---|
| Length (cm) | 25.4 |
| Width (cm) | 12.7 |
| HS Code | 8481803055 |
|---|---|
| Country Of Origin | CN |
| Weight (kg) | 4.77 |
| Style | Model | Pipe Size | Connection Type | Top Of Handle To Inlet Center | Inlet To Outlet Length | Handle Material | Handle Type | Max. Water Pressure | Body Material | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | SV35116014 | 1 1/2" | Class 150 Flange | 11" | 6 1/2" | Ductile Iron | Wheel | 275 psi | 316 Stainless Steel | $1,877.62 | |
| A | SV35116020 | 2" | Class 150 Flange | 12.593" | 7" | Ductile Iron | Wheel | 275 psi | 316 Stainless Steel | $1,971.46 | |
| A | SV35116030 | 3" | Class 150 Flange | 16.406" | 8" | Ductile Iron | Wheel | 275 psi | 316 Stainless Steel | $3,503.71 | |
| A | SV35116040 | 4" | Flanged | 20" | 9" | Cast Iron | Hand Wheel | 275 psi | - | $4,404.42 |
