| Item | Swivel Plate Caster |
|---|---|
| Application | Dollies, Floor Trucks, Material Handling Containers, Platform Trucks, Shop Carts, Warehouse Trucks, Waste Disposal Trucks |
| Caster Brake Type | No Brake Included |
| Caster Frame Material | Steel |
| Caster Sub-type | Swivel |
| Core Color | Black |
| Core Material | Phenolic |
| Durometer | 90 Shore D |
| Features | Floor Protective |
| Frame Finish | Zinc Plated |
| Frame Material | Steel |
| Includes Thread Guards | No |
| Inside Bolt Hole Spacing | 3" x 3" |
| Load Rating | 1200 lbs. |
| Mounting Height | 7 1/2" |
| Mounting Plate Bolt Hole Pattern | B |
| Mounting Plate Size | 4" x 4 1/2" |
| Mounting Plate Size & Bolt Hole Pattern | 4" X 4 1/2" ( B ) |
| Non-marking | Yes |
| Number Of Mounting Holes | 4 |
| Number Of Wheels | 1 |
| Outside Bolt Hole Spacing | 2 5/8" x 3 5/8" |
| Overall Height | 7 1/2" |
| Plate Size | 4" x 4 1/2" |
|---|---|
| Plate Thickness | 1/4" |
| Plate Type | B |
| Raceway Type | Single Ball Hardened |
| Replacement Wheel | P-PH-060X020/050R |
| Standards | Icwm |
| Swivel Construction | Kingpinless |
| Swivel Lock Type | No Lock Included |
| Swivel Raceway Type | Single Ball |
| Swivel Radius | 4 19/32" |
| Tread Shape | Standard |
| Wheel Bearing Type | Roller |
| Wheel Bearings | Roller |
| Wheel Color | Black |
| Wheel Core Material | Phenolic |
| Wheel Diameter | 6" |
| Wheel Material | Phenolic |
| Wheel Width | 2" |
| Wheel/tread Color | Black |
| Wheel/tread Hardness | Rockwell 102E |
| Wheel/tread Hardness Rating | Hard |
| Wheel/tread Material | Phenolic |
| Height (cm) | 18.8 |
|---|---|
| Length (cm) | 15.49 |
| Width (cm) | 9.65 |
| HS Code | 3926909980 |
|---|---|
| Country Of Origin | GB |
| Weight (kg) | 3.276 |
| Style | Model | Inside Bolt Hole Spacing | Outside Bolt Hole Spacing | Wheel Width | Wheel Bearing Type | Load Rating | Mounting Plate Bolt Hole Pattern | Wheel/tread Material | Mounting Height | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | TSK 125 NT0E | 2 5/8" x 3" | 3" x 3 5/8" | 1 3/4" | Plain | 550 lbs. | A | Nythane | 6 1/2" | $124.99 | |
| A | TSK 200 NT0E | 3" x 3" | 2 5/8" x 3 5/8" | 1 3/4" | Plain Bore | 880 lbs. | - | - | - | $184.06 | |
| B | TSK 200 NY2H | 2 5/8" x 3" | 3" x 3 5/8" | 2" | Precision Ball | 2200 lbs. | A | Nylon | 9 1/2" | $351.44 | |
| C | TSK 100 RP1G | 2 5/8" x 3" | 3" x 3 5/8" | 2" | Roller | 700 lbs. | A | Phenolic | 5 5/8" | $90.55 | |
| D | TSK 125 GR2H | 2 5/8" x 3" | 3" x 3 5/8" | 1 5/8" | Precision Ball | 440 lbs. | A | Rubber | 6 1/2" | $162.07 | |
| C | TSK 125 RP1G | 3" x 3" | 2 5/8" x 3 5/8" | 2" | Roller | 1000 lbs. | B | Phenolic | 6 1/2" | $119.05 | |
| D | TSK 150 GR2H | 2 5/8" x 3" | 3" x 3 5/8" | 1 5/8" | Precision Ball | 660 lbs. | A | Rubber | 7 1/2" | $193.70 |
