| Item | CJ Series Hub |
|---|---|
| Angular Displacement | 0.09" |
| Bore Size | 2 3/8" |
| Bore Type | Bored |
| Color | Gray |
| Coupling Size | 55 |
| Coupling Type | Jaw |
| Dimension G | 1.18" |
| Dimension Hd | 4 18/25" |
| Distance Between Spider And Hub Face (dimension Cl) | 4/25" |
| Hub Material | Cast Iron |
| Hub Type | B |
| Keyway | Keyway |
| Keyway Depth | 5/8" x 5/16" |
| Keyway Size | 5/8" x 5/16" |
| Keyway Width | 5/8" x 5/16" |
| Length Through Bore | 2 14/25" |
| Max. Angular Displacement (Δ Ka), N=1500 [1/min] | 1.1° |
| Max. Axial Displacement | 0.87" |
|---|---|
| Max. Bore | 2 19/25" |
| Max. Operating Temp. | -50°F to +248°F |
| Max. Radial Displacement | 0.014" |
| Max. Speed | 4750 RPM |
| Max. Torque | 7250 lbs.-in. |
| Min. Bore | 1.89" |
| Nominal Torque (with 92 Shore A Spider) | 3625 lbs.-in. |
| Normal Temperature Range (with 80 Shore A, 92 Shore A, And 95/98 Shore A Spiders) | -40°F to +212°F |
| Outside Dia. | 4 18/25" |
| Overall Coupling Length | 6.3" |
| Set Screw Style Coupling Location Size | 0.79" |
| Spider Inside Dia. | 2 9/25" |
| Spider Outside Dia. | 4 18/25" |
| Spider Thickness (dimension W) | 0.87" |
| Style | Bored |
| System Of Measurement | Imperial |
| Height (cm) | 16 |
|---|---|
| Length (cm) | 11.99 |
| Width (cm) | 11.99 |
| Country Of Origin | US |
|---|---|
| Weight (kg) | 4.1175 |
