| Item | CJ Series Hub |
|---|---|
| Angular Displacement | 0.03" |
| Bore Size | 0.312" |
| Bore Type | Solid |
| Color | Metallic |
| Coupling Size | 14 |
| Coupling Type | Jaw |
| Dimension G | 0.51" |
| Dimension Hd | 1.18" |
| Distance Between Spider And Hub Face (dimension Cl) | 0.06" |
| Hub Material | Metal , Powder Metal |
| Hub Type | B |
| Keyway Size | No Keyway |
| Keyway Type | No Keyway |
| Length Through Bore | 0.43" |
| Max. Angular Displacement (Δ Ka), N=1500 [1/min] | 1.2° |
| Max. Axial Displacement | 1/25" |
| Max. Bore | 0.63" |
|---|---|
| Max. Operating Temp. | -50°F to +248°F |
| Max. Radial Displacement | 0.007" |
| Max. Speed | 1900 RPM |
| Max. Torque | 133 lbs.-in. |
| Nominal Torque (with 92 Shore A Spider) | 66 lbs.-in. |
| Normal Temperature Range (with 80 Shore A, 92 Shore A, And 95/98 Shore A Spiders) | -40°F to +212°F |
| Outside Dia. | 1.18" |
| Overall Coupling Length | 1.38" |
| Screw Size | #8-32 |
| Screw Thread Per Inch | #8-32 |
| Set Screw Style Coupling Location Size | 1/5" |
| Spider Outside Dia. | 1.18" |
| Spider Thickness (dimension W) | 0.39" |
| Style | Bored |
| System Of Measurement | Imperial |
| Height (cm) | 3 |
|---|---|
| Length (cm) | 3.51 |
| Width (cm) | 3 |
| Country Of Origin | US |
|---|---|
| Weight (kg) | 0.054 |
