| Item | L Type Spider |
|---|---|
| Angular Misalignment | 1° |
| Chemical Resistance | Very Good |
| Color | Blue |
| Coupling Type | Jaw |
| Cubic Inches | 8.217 cu. in. |
| Damping Capacity | Low |
| Dimension A | 3.31" |
| Dimension B | 0.45" |
| Dimension W | 3/4" |
| Insert Material | Elastomer |
| Inside Dia. | 1.18" |
|---|---|
| Material | Urethane |
| Max. Bore | 1 5/8" |
| Max. Parallel Misalignment | 0.015" |
| Normal Temp. Range | -30°F to +160°F |
| Outside Dia. | 3.31" |
| Parallel Misalignment | 0.015" |
| Shore Hardness | 55D, L050 - L110, 90 - 95A, L150 - L230 |
| Style | Open |
| Thickness | 3/4" |
| Torque | 1188 lbs.-in. |
| Height (cm) | 1.9 |
|---|---|
| Length (cm) | 8.41 |
| Width (cm) | 8.41 |
| Country Of Origin | US |
|---|---|
| Weight (kg) | 0.063 |
| Style | Model | Material | Parallel Misalignment | Angular Misalignment | Outside Dia. | Color | Chemical Resistance | Normal Temp. Range | Damping Capacity | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 68514410620 | SOX Rubber | 0.015" | 1° | 1 3/4" | Black | Good | -40°F to +212°F | High | $10.70 | |
| B | 68514434517 | Bronze | 0.01" | 0.5° | - | Bronze | Excellent | -40°F to +450°F | None | $614.26 | |
| A | 68514437881 | SOX Rubber | 0.015" | 1° | 4 1/2" | Black | Good | -40°F to +212°F | High | $74.11 | |
| C | 68514412400 | Hytrel | 0.015" | 0.5° | - | Tan | Excellent | -60°F to +250°F | Low | $213.71 | |
| A | 68514410968 | SOX Rubber | 0.015" | 1° | 2 3/25" | Black | Good | -40°F to +212°F | High | $20.49 | |
| A | 68514412406 | SOX Rubber | 0.015" | 1° | - | Black | Good | -40°F to +212°F | High | $67.03 | |
| A | 68514437880 | SOX Rubber | 0.015" | 1° | 3 3/4" | Black | Good | -40°F to +212°F | High | $48.84 |
