| Item | Explosion Proof Motor |
|---|---|
| Ambient Temp. | 40°C |
| Conduit Box Position | F1 Only |
| Duty Cycle | Continuous |
| Efficiency | 75% |
| Enclosure Type | Explosion Proof Non Ventilated |
| Frame | 56C |
| Frequency | 60 Hz |
| Full Load Amps | 0.44A |
| Hazardous Location Class | Class 1 C, Class D, Class 2 F, Class G |
| Hp | 1/4 hp |
| Insulation Class | Class B |
| Motor Mounting Position | Horizontal |
|---|---|
| Motor Type | Squirrel Cage Induction Run |
| Mounting Type | C Face, Footless |
| Nameplate Rpm | 1800 RPM |
| Nema Design | B |
| Output Rating | 0.187 kW |
| Phase | 3 |
| Power | 0.187 kW |
| Service Factor | 1 |
| Temp. Code | T3B |
| Thermal Protection | Automatic |
| Voltage | 575V AC |
| Height (cm) | 21.89 |
|---|---|
| Length (cm) | 41.61 |
| Width (cm) | 26.67 |
| HS Code | 8501514040 |
|---|---|
| Country Of Origin | MX |
| Weight (kg) | 11.25 |
| Style | Model | Voltage | Hp | Nameplate Rpm | Motor Thermal Protection | Motor Design | Mounting Type | Full Load Amps | Frame Material | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 056T17E5311 | 208-230/460V AC | 1/3 hp | 1725 RPM | Auto | 3-Phase | Face | 1.20-1.20/0.6A | Rolled Steel | $952.21 | |
| B | 056T17G5315 | 208-230/460V AC | 1/2 hp | 1725 RPM | Automatic | 3 Phase | Face | 2.4-2.3/1.2A | Rolled Steel | $1,001.47 | |
| C | 056T17E5310 | 208-230/460V AC | 1/4 hp | 1725 RPM | Auto | 3-Phase | C Face, Footless | 1.10-1.1/0.55A | Steel | $722.81 |
