| Item | Low Voltage Thermostat |
|---|---|
| Application | Heat Only |
| Color | White |
| Compatible System Type | Electric Forced Air Furnaces, Gas Forced Air Furnaces |
| Contact Type | Snap Action |
| Control Range | +50°F to +90°F |
| Control Type | Slide Switch |
| Dehumidification Control | No |
| Depth | 1 1/4" |
| Digit Size | Standard |
| Display Type | Analog |
| Dual Transformer Compatible | No |
| Electrical Connection Type | Hardwired |
| Fan Settings | No Fan Setting |
| Fan Switching | No |
| Height | 3" |
| Housing Color | White |
| Humidification Control | No |
| Includes | Dealer Logo Pocket |
| Includes Positive Off | No |
| Maximum Control Temperature | 90°F |
| Maximum Operating Humidity | 90% |
| Mercury Free | Yes |
| Millivolt Compatible | No |
| Minimum Control Temperature | 50°F |
| Minimum Operating Humidity | 0% |
|---|---|
| Mounting | Horizontal |
| Mounting Direction | Vertical |
| Mounting Position | Horizontal |
| Number Of Cooling Stages - Conventional System | 0 |
| Number Of Cooling Stages - Heat Pump System | 0 |
| Number Of Heating Stages - Conventional System | 1 |
| Number Of Heating Stages - Heat Pump System | 0 |
| Overall Depth | 7/8" |
| Overall Height | 3 1/8" |
| Overall Width | 3 1/8" |
| Power Method | Hardwired |
| Shape | Square |
| Stages | 1 H/0 C Conventional |
| Stages Heat Pump | 0 H/0 C Heat Pump |
| Stages Heating/cooling | 1 H/0 C Conventional, 0 H/0 C Heat Pump |
| System Settings | On |
| System Switching | No |
| Temp. Control Range | +50°F to +90°F |
| Temperature Scale | Fahrenheit |
| Temperature Sensitivity | -3°F to +3°F |
| Terminal Designations | R, W |
| Thermostat Type | Low Voltage |
| Voltage | 18-30V AC |
| Width | 3" |
| Height (cm) | 11.43 |
|---|---|
| Length (cm) | 8.13 |
| Width (cm) | 3.3 |
| HS Code | 9032100090 |
|---|---|
| Country Of Origin | CN |
| Weight (kg) | 0.09 |
| Style | Model | Display Type | Application | Terminal Designations | Programming Capability | Overall Width | Voltage | Dehumidification Control | Control Type | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | T8034N1007 | Analog | Heat And Cool | B, G, O, R, Rc, W, Y | - | 4 3/4" | 20-30V AC | No | Slide Switch | $99.91 | |
| B | T822K1018 | Analog | Heat Only | R, W | - | 2 7/8" | 20-30V AC | No | Slide Switch | $134.26 | |
| C | T834N1002 | Analog | Heat And Cool | B, G, O, R, Rc, W, Y | - | 2 7/8" | 20-30V AC | No | Slide Switch | $99.46 | |
| D | T87K1007 | Analog | Heat Only | R, W, Y | - | 4 13/16" | 20-30V AC | No | Exposed Dial | $93.59 | |
| E | TH1210DH1001 | Digital | - | - | - | 4 5/8" | 20-30V AC | No | Slide Switch | - | RFQ
|
| F | TH3210D1004 | Digital | Heat Or Cool | Aux, B, C, E, G, L, O, R, Y | Not Programmable | 5 3/8" | 24V AC | No | Push Button, Slide Switch | $168.66 | |
| G | TH8320R1003 | Digital | Heat And Cool | A-L/A, C, G, K, R, Rc, S1 S1, W-O/B, W2-Aux/E, Y, Y2 | 7 Days | 4 15/16" | 18-30V AC | Yes | Touch Screen | $645.99 |
