| Item | Hydraulic Gear Pump |
|---|---|
| Cover Material | Cast Iron |
| Discharge Connection Size | 3/4"-16 |
| Displacement | 0.37 cu. in./rev. |
| Displacement Per Revolution | 0.37 cu. in./rev. |
| End Cap Material | Cast Iron |
| Gpm @ 1800 Rpm & 1000 Psi | 2.7 GPM |
| Gpm @ 3600 Rpm & 1000 Psi | 5.4 GPM |
| Housing | Aluminum |
| Housing Material | Aluminum |
| Intake Connection | 7/8"-14 |
| Max. Continuous Pressure | 4000 psi |
| Max. Speed | 4000 RPM |
| Media Intake Connection Size | 7/8"-14 |
|---|---|
| Min. Rpm | 500 RPM |
| Motor Speed (maximum) | 4000 RPM |
| Motor Speed (minimum) | 500 RPM |
| Mounting | SAE A Bolted |
| Mounting Type | 2 Bolt Sae A |
| Nominal Gpm @ 1200 Rpm | 1.9 GPM |
| Overall Width | 3 3/5" |
| Rotation | CW |
| Shaft Extension (in.) | 3/4" x 1 1/4" |
| Shaft Outer Diameter | 3/4" |
| Shaft Type | Keyed |
| Width | 3.62" |
| Height (cm) | 16.26 |
|---|---|
| Length (cm) | 16 |
| Width (cm) | 16 |
| HS Code | 8413919050 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 2.43 |
Hydraulic gear pumps operate by trapping fluid between the teeth of rotating gears (two or three) and move a cavity that rotates rather than reciprocates. These pumps use less liquidy materials for chemical compatibility.
| Style | Model | Rotation | Displacement | Max. Continuous Pressure | Mounting | Max. Speed | Gpm @ 1800 Rpm & 1000 Psi | Nominal Gpm @ 1200 Rpm | Shaft Extension (in.) | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 1850222 | Right Hand | 0.183 cu. in./rev. | 4000 psi | SAE AA Bolted | 4000 RPM | 1.4 GPM | 1 GPM | 1/2" x 1 1/2" | $576.01 | |
| A | 1850223 | CW | 0.214 cu. in./rev. | 4000 psi | SAE AA Bolted | 4000 RPM | 1.6 GPM | 1.1 GPM | 1/2" x 1 1/2" | $673.06 | |
| A | 1850224 | CW | 0.244 cu. in./rev. | 4000 psi | SAE AA Bolted | 4000 RPM | 1.8 GPM | 1.3 GPM | 1/2" x 1 1/2" | $645.56 | |
| A | 1850225 | Right Hand | 0.305 cu. in./rev. | 4000 psi | SAE AA Bolted | 4000 RPM | 2.2 GPM | 1.6 GPM | 1/2" x 1 1/2" | $630.77 | |
| A | 1850226 | CW | 0.427 cu. in./rev. | 4000 psi | SAE AA Bolted | 3450 RPM | 3.1 GPM | 2.2 GPM | 1/2" x 1 1/2" | $653.61 | |
| A | 1850227 | CW | 0.61 cu. in./rev. | 3200 psi | SAE AA Bolted | 2800 RPM | 4.5 GPM | 3.2 GPM | 1/2" x 1 1/2" | $711.20 | |
| A | 1800289 | CW | 0.49 cu. in./rev. | 4000 psi | SAE A Bolted | 4000 RPM | 3.6 GPM | 2.5 GPM | 3/4" x 1 1/4" | $390.77 |
