| Item | Contact Block |
|---|---|
| Ac Contact Rating | 6A @ 240V |
| Actuator Type | Front, Spring Cage |
| Button Color | Black |
| Color | Black |
| Compatible Operator | Push Button |
| Compatible With Series | M22, M22M |
| Contact Configuration | NO-NC |
| Contact Form | 1NO/1NC |
| Dc Contact Rating | 6A @ 240V |
| Height | 1.54" |
| Includes Mounting Block | Mounting Block Included |
| Length | 1.03" |
| Manufacturer Warranty Length | 1 yr. |
|---|---|
| Mounting Location | Front |
| Nema Contact Rating Designation | A600/Q300 |
| Notes | All NC Contact Blocks Are Positively Driven Contact. Not Stackable. |
| Panel Mounting Hole Diameter | 22 mm |
| Special Features | NC Contact Blocks Are Positively Driven |
| Switch Action | Momentary/Break Before Make |
| Terminal Connection Type | Spring Cage Terminals |
| Type | Contact Block |
| Warranty | Eaton Selling Policy 25-000, One (1) Year From The Date Of Installation Of The Product Or Eighteen (18) Months From The Date Of Shipment Of The Product, Whichever Occurs First. |
| Width | 1.18" |
| Standards | BUREAU VERITAS, CCC, CE, CSA, GOST-R, LLOYD'S REGISTER |
| Height (cm) | 3.91 |
|---|---|
| Length (cm) | 2.62 |
| Width (cm) | 3 |
| Country Of Origin | US |
|---|---|
| Weight (kg) | 0.0383 |
| Style | Model | Contact Form | Terminal Connection Type | Height | Type | Color | Nema Contact Rating Designation | Application | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|
| A | M22-K01 | 1NC | Screw Clamp Terminals | - | - | Black | A600/Q300 | Operator | $27.00 | |
| B | M22-K10 | 1NO | Screw Clamp Terminals | - | - | Black | A600/Q300 | - | $25.74 | |
| C | M22-CK01 | 1NC | Spring Cage Terminals | - | - | Black | A600/Q300 | Operator | $38.79 | |
| D | M22-CK10 | 1NO | Spring Cage Terminals | - | - | Black | A600/Q300 | Operator | $36.60 | |
| E | M22-KC10 | 1NO | Spring Cage Terminals | 0.1" | Contact Block | Black | A600/Q300 | - | $21.60 | |
| F | M22-KC01 | 1NC | Spring Cage Terminals | 1.03" | M22 | Black | A600/Q300 | - | $20.13 |
