| Item | Motorized Damper |
|---|---|
| Application | Motorized |
| Axle Material | Aluminum |
| Blade Material | Aluminum |
| Blade Material Thickness | 0.1" |
| Blade Orientation | Parallel Blades |
| Blade Type | Flat Blade |
| Bushing Material | Nylon |
| Counterbalanced | No |
| Damper Finish | Mill Finish |
| Damper Type | Dynamic |
| Features | Frame Thickness Is 0.125 In, Blade Thickness Is 0.080 In |
| Flange Type | Reversed Flange |
| Flange Width | 1 1/2" |
| For Duct Shape | Square |
| For Fan Dia. | 48" |
| Frame Less Flange Area | 48 sq. in. |
| Frame Material | Aluminum |
| Frame Material Thickness | 0.1" |
| Frequency | 100-240 Hz |
| Full Load Amps | 3A |
| Jamb Seal Material | Stainless Steel |
| Material | Extruded Aluminum |
|---|---|
| Max. Air Velocity | 3500 FPM |
| Max. Velocity | 3500 FPM |
| Motor Bracket Extension | 10 1/4" |
| Motor Included | Yes |
| Mounting Holes | 0.281" x 0.5" |
| Mounting Position | Horizontal |
| Number Of Panels | 1 |
| Operation | Power Open, Spring Return |
| Overall Dia. | 51" |
| Overall Height | 51" |
| Overall Length | 13 1/4" |
| Overall Square | 51" |
| Overall Width | 51" |
| Phase | 1 |
| Rough Opening Dia. | 49" |
| Rough Opening Length | 49" |
| Rough Opening Shape | Square |
| Rough Opening Width | 49" |
| Sq. Opening Required | 49" |
| Type | Power Open, Single Panel, Spring Return |
| Voltage | 100-240V |
| Height (cm) | 129.54 |
|---|---|
| Length (cm) | 33.66 |
| Width (cm) | 129.54 |
| HS Code | 8501402040 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 25.65 |
| Style | Model | Frame Material | Mounting Position | Number Of Panels | Voltage | Operation | Mounting Holes | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|
| A | 2LRY6 | Steel | Horizontal | 1 | - | - | - | $255.50 | |
| A | 2LRY7 | Steel | Horizontal | 1 | - | - | - | $253.36 | |
| A | 2LRY8 | Steel | Horizontal | 1 | - | - | - | $247.82 | |
| A | 2LRY9 | Steel | Horizontal | 1 | - | - | - | $305.59 | |
| A | 2LRZ1 | Steel | Horizontal | 1 | - | - | - | $358.06 | |
| B | 3C131 | Aluminum | Horizontal, Vertical | 1 | 100-240V | Power Open, Spring Return | 0.281" x 0.5" | $652.28 | |
| C | 3C188 | Aluminum | Horizontal, Vertical | 2 | 24-240V | Power Open, Spring Return | 0.281" x 0.5" | $1,141.99 |
