| Item | Chain Link |
|---|---|
| Ansi Chain Size | 160 |
| Breaking Strength | 58000 lbs. |
| Bushing Dia. | 0.79" |
| Bushing Dia. (in.) | 0.79" |
| Chain Construction | Riveted Pin |
| Chain Link Overall Width | 2.94" |
| Chain No. | 160 |
| Chain Overall Width | 2 15/16" |
| Chain Roller Dia. | 1 1/8" |
| Chain Size - Sprockets | 160 |
| Connecting End To Center Line | 1.416" |
| Heavy Series | No |
| Hole Dia. | 0.564" |
| Industry Chain Pitch | 2" |
| Inside Pin Dia. | 14/25" |
| Inside Width | 1 1/4" |
| Link Type | Offset |
| Material | Steel |
| Max. Allowable Load | 11880 lbs. |
| Maximum Operating Temperature | 150°F |
| Minimum Operating Temperature | 10°F |
|---|---|
| Number Of Strands | 1 |
| Outside Pin Dia. | 14/25" |
| Overall Width | 2.691" |
| Pin Contruction | Riveted Pin |
| Pin Hole Diameter | 9/16" |
| Pin Length | 2.94" |
| Pin Link Plate Thickness | 1/4" |
| Pin Outside Dia. | 9/16" |
| Pitch | 2" |
| Plate Height | 1 7/8" |
| Plate Thickness | 1/4" |
| Rivet End To Center Line | 1.275" |
| Roller Chain Link Item | Offset Link |
| Roller Chain Link Type | Standard Riveted |
| Roller Dia. | 1 1/8" |
| Roller Link Plate Height | 1.882" |
| Tensile Strength | 50000 lbf. |
| Type | Single Strand Offset |
| Width Between Roller Link Plates | 1 1/4" |
| Working Load Limit | 11880 lbs. |
| Height (cm) | 4.83 |
|---|---|
| Length (cm) | 21.08 |
| Width (cm) | 15.75 |
| HS Code | 7315900000 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 0.5265 |
| Style | Model | Pitch | Ansi Chain Size | Tensile Strength | Roller Dia. | Inside Pin Dia. | Pin Length | Roller Link Plate Height | Pin Link Plate Thickness | Pkg. Qty. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 2YDZ8 | 1/2" | 40NP | 2481 lbf. | 0.313" | 0.155" | 0.83" | 0.475" | 0.06" | 5 | $9.64 | |
| A | 2YDZ9 | 5/8" | 50NP | 4880 lbf. | 2/5" | 1/5" | 1.01" | 0.594" | 2/25" | 5 | $11.26 | |
| A | 2YEA1 | 3/4" | 60NP | 7030 lbf. | 0.469" | 0.233" | 1.23" | 0.709" | 0.094" | 5 | $14.40 | |
| B | 2YEA2 | 1/2" | 40NP | 2481 lbf. | 0.313" | 0.155" | 0.83" | 0.475" | 0.06" | 5 | $13.17 | |
| B | 2YEA3 | 5/8" | 50NP | 4880 lbf. | 2/5" | 1/5" | 1.01" | 0.594" | 2/25" | 5 | $19.59 | |
| B | 2YEA4 | 3/4" | 60NP | 8500 lbs. | 0.469" | 0.233" | 1.23" | 0.709" | 0.094" | 5 | $24.61 | |
| C | 2YEA5 | 3/8" | 35 | 1760 lbf. | 1/5" | 0.141" | 16/25" | 0.356" | 0.05" | 5 | $9.96 |
