| Item | Electric Chain Hoist |
|---|---|
| Amperage Draw | 10A |
| Amps @ Low Volts | 10A |
| Body Depth | 7 3/8" |
| Body Finish | Powder Coated |
| Body Length | 22 5/16" |
| Body Material | Steel |
| Body Width | 8 5/8" |
| Brake Type | Load |
| Capacity | 1000 lbs. |
| Chain Finish | Powder Coated |
| Chain Grade | Grade 80 |
| Chain Material | Alloy Steel |
| Classification | H2 |
| Clutch | Overload Limiting |
| Clutch Type | Overload Limiting |
| Color | Red |
| Configuration | Hook Mounted - No Trolley |
| Control | Push Button Pendant |
| Control Cord | 16 ft. |
| Controller Cord Length | 20 ft. |
| Duty Classification | H2 - Light Duty |
| Features | Not Applicable |
| Finish | Powder Coated |
| Fixed Lift Speed | 16 FPM |
| For Max. Beam Flange Height | Not Applicable |
| For Max. Beam Height | Not Applicable |
| For Maximum Beam Flange Width | Not Applicable |
| For Min. Beam Flange Height | Not Applicable |
| For Minimum Beam Flange Width | Not Applicable |
| For Minimum Beam Height | Not Applicable |
| For Outdoor Use | No |
| Headroom | 19 3/32" |
| Headroom Size | 19 3/32" |
| Housing Depth | 7 3/8" |
| Housing Length | 22 5/16" |
| Housing Width | 8 5/8" |
| Includes | Chain Container |
|---|---|
| Includes Brake | Brake Included |
| Includes Clutch | Clutch Included |
| Ip Rating | Not Applicable |
| Lift | 20 ft. |
| Lift Speed | 16 FPM |
| Lifting Capacity | 1000 lbs. |
| Lifting Hook Material | Steel |
| Lifting Hook Opening Width | 19 3/32" |
| Lifting Hook Type | Hook With Safety Latch |
| Load Capacity | 1000 lbs. |
| Lubrication | Grease |
| Manufacturers Warranty Length | 1 yr. |
| Max Current Draw | 10A |
| Maximum Lift Speed | Not Applicable |
| Maximum Lifting Length | 20 ft. |
| Min. Between Hooks | 19 3/32" |
| Min. Radius Curve | Not Applicable |
| Minimum Lift Speed | Not Applicable |
| Minimum Retracted Length | 19 3/32" |
| Motor Hp | 5/8 hp |
| Mount Type | Hook Mounted - No Trolley |
| Number Of Load Chains | 1 |
| Number Of Reeves | 1 |
| Number Of Speeds | 1 |
| Operating Voltage | 115V AC |
| Overload Protection Included | Yes |
| Pendant Ip Rating | IP54 |
| Phase | 1 |
| Reeving | 1 |
| Resistance Properties | Not Applicable |
| Starts And Stops Per Hour | 75 |
| Thermal Protection | Included |
| Tonnage - Lifting Capacity | 0.5 ton. |
| Trolley Wheel Dia. | Not Applicable |
| Trolley Wheel Material | Not Applicable |
| standard | ANSI/ASME B30.16, CUL LISTED, NEMA CERTIFIED |
| Height (cm) | 36.83 |
|---|---|
| Length (cm) | 59.69 |
| Width (cm) | 49.53 |
| HS Code | 8425110000 |
|---|---|
| Country Of Origin | CN |
| Weight (kg) | 33.975 |
