| Item | Keyless Bushing |
|---|---|
| Bolt Size | M6 x 45 |
| Finish | Oil Dipped |
| For Shaft Diameter | 1 3/4" |
| Keyless Bushing Type | Multi Screw Locking Assembly |
| Material | Steel |
| Maximum Transmitted Torque | 2363 lbs.-ft. |
| Number Of Locking Bolts | 7 |
| Outside Dia. | 2.953" |
| Outside Diameter Tolerance | +0.002" |
|---|---|
| Outside Diameter/for Bore Diameter | 2 15/16" |
| Overall Length | 2.441" |
| Overall Width | 2.441" |
| Screw Thread Size | M6 x 45 |
| Shaft Dia. | 1 3/4" |
| Transmissible Torque | 2363 lbs.-ft. |
| Withstand Temp. | 0°F to +400°F |
| Flange Type | None |
| Height (cm) | 6.5 |
|---|---|
| Length (cm) | 8.2 |
| Width (cm) | 8.2 |
| HS Code | 8483608000 |
|---|---|
| Country Of Origin | IT |
| Weight (kg) | 0.9 |
| Style | Model | Finish | Overall Width | Maximum Transmitted Torque | Number Of Locking Bolts | Bolt Size | Transmissible Torque | Hub Contact Pressure | Material | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | C405E-100 | Oil Dipped | 1.811" | 626 lbs.-ft. | 6 | M6 x 35 | 626 lbs.-ft. | 19493 psi | Steel | $332.47 | |
| A | C405E-125 | Oil Dipped | 2.362" | 914 lbs.-ft. | 7 | M6 x 45 | 914 lbs.-ft. | 14715 psi | Steel | $331.14 | |
| A | C405E-137 | Oil Dipped | 2.362" | 1005 lbs.-ft. | 7 | M6 x 45 | 1005 lbs.-ft. | 14715 psi | Steel | $351.79 | |
| A | C405E-143 | Oil Dipped | 2.362" | 1051 lbs.-ft. | 7 | M6 x 45 | 1051 lbs.-ft. | 14715 psi | Steel | $265.17 | |
| A | C405E-150 | Oil Dipped | 2.441" | 2026 lbs.-ft. | 7 | M6 x 45 | 2026 lbs.-ft. | 21752 psi | Steel | $525.73 | |
| A | C405E-193 | Oil Dipped | 2.913" | 2990 lbs.-ft. | 8 | M8 x 55 | 2990 lbs.-ft. | 18009 psi | Steel | $458.86 | |
| A | C405E-200 | Oil Dipped | 2.913" | 3087 lbs.-ft. | 8 | M8 x 55 | 3087 lbs.-ft. | 18009 psi | Steel | $467.97 |
