| Item | Wall Exhaust Fan |
|---|---|
| Assembled | Assembled |
| Bearing Type | Ball |
| Blade Dia. | 10" |
| Blade Material | Aluminum |
| Cfm @ 0.000-in. Sp | 620 CFM |
| Control Type | Toggle Switch |
| Dimension A | 15 1/4" |
| Dimension B | 17 1/2" |
| Dimension C | 4" |
| Dimension D | 14" |
| Drive Package Included | No |
| Drive Package With Motor Included | No |
| Drive Type | Direct Drive |
| Electrical Connection | Hardwired |
| Exhaust Airflow @ 0.000 In Sp | 620 CFM |
| Exhaust Airflow @ 0.100 In Sp | 530 CFM |
| Exhaust/supply Fan Item | Exhaust Fan |
| Fits Square Opening | 13" x 14" |
| Flange Depth | 1 1/4" |
| Flange Width | 1 1/4" |
| For Cut-out Height | 13" |
| For Cut-out Width | 14" |
| For Cutout Dia. | 14" |
| For Maximum Wall Thickness | 4" |
| For Min. Wall Thickness | 4" |
| For Use With | General Ventilation Applications, Hazardous Locations, Explosion Proof, Shutter Mounted Exhaust Fan |
| Frame Finish | Powder Coated |
| Frame Material | Steel |
| Guard Finish | Chrome |
| Guard Material | Steel |
| Guard Type | Intake |
| Height | 7 1/8" |
| Housing Material | Steel |
| Includes Dehumidistat | No |
| Includes Grill | No |
| Includes Motor | No |
| Max. Ambient Temp. | 104°F |
| Max. Depth | 17 1/2" |
| Max. Exhaust Airflow @ 0.000 In Sp | 620 CFM |
| Maximum Airflow | 620 CFM |
|---|---|
| Maximum Noise Level | 6.5 sones |
| Method Of Construction | Stamped |
| Motor Enclosure | Totally Enclosed Fan Cooled |
| Motor Enclosure Design | Explosion Proof Fan Cooled |
| Motor Hp | 1/3 hp |
| Motor Insulation | Class B |
| Motor Speed | 1625 RPM |
| Motor Type | EPFC |
| Mounting Holes O.c. | 14" |
| Mounting Orientation | Horizontal |
| Mounting Position | Horizontal |
| Nameplate Voltage | 115/230V AC |
| No. Of Blades | 3 |
| Noise Level @ 0.000 In Sp @ 5 Ft | 6.5 sones |
| Noise Level @ 0.100 In Sp @ 5 Ft | 6.5 sones |
| Number Of Blades | 3 |
| Number Of Fans | 1 |
| Number Of Speeds | 1 |
| Outside Dia. | 7 1/8" |
| Overall Depth | 17 1/2" |
| Overall Dia. | 15 1/4" |
| Overall Height | 15 1/4" |
| Overall Width | 15 1/4" |
| Phase | 1 |
| Propeller Dia. | 10" |
| Propeller Material | Aluminum |
| Shaft Dia. | 1/2" |
| Speed Controllable | No |
| Supply Airflow @ 0.000 In Sp | 620 CFM |
| Thermal Protection | Yes |
| Type | Explosion Proof |
| Vent Design | Ductless |
| Ventilation Type | Exhaust |
| Venturi Clearance Dia. | 1/8" |
| Venturi Depth | 5/8" |
| Venturi Dia. | 1/8" |
| Voltage | 115/230V |
| Wattage | 250 W |
| Width | 15 1/4" |
| Height (cm) | 40.64 |
|---|---|
| Length (cm) | 57.15 |
| Width (cm) | 48.26 |
| HS Code | 8414596095 |
|---|---|
| Country Of Origin | CA |
| Weight (kg) | 22.5765 |
| Style | Model | Cfm @ 0.000-in. Sp | Mounting Holes O.c. | Frame Material | Voltage | Phase | Motor Hp | Motor Enclosure Design | Number Of Blades | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | SD08-XPF | 320 CFM | 12" | Steel | 115/230V | 1 | 1/3 hp | Explosion Proof Fan Cooled | 3 | $1,186.31 |
