| Item | Spring Check Valve |
|---|---|
| 3-a Compliance | Not Rated |
| Application - Valves | General Purpose |
| Body Material | Bronze |
| Check Mechanism | Poppet |
| Connection Gender - Side 1 | Female |
| Connection Gender - Side 2 | Female |
| Connection Size - Side 1 | 1" |
| Connection Size - Side 2 | 1" |
| Connection Type | FNPT x FNPT |
| Connection Type - Side 1 | NPT |
| Connection Type - Side 2 | NPT |
| Cracking Pressure | 0.5 psi |
| Flow Coefficient | 15 |
| Flow Design | Single |
| Flow Rate | 18 GPM |
| For Media | Water |
| Full Flow - Valves | No |
| Includes Counterweight | No Counterweight |
| Length | 3 1/2" |
| Manufacturer Warranty | 5 yrs. |
| Material | Lead Free Brass |
| Max. Pressure (cwp) | 400 psi |
| Max. Pressure (steam) | Not Rated |
| Max. Steam Pressure - Valves | Not Rated |
| Max. Temp. | 180°F |
| Max. Water Pressure | 400 psi |
| Media Temp. Range | 35°F to 180°F |
|---|---|
| Media Temperature Range | 35°F to 180°F |
| Mounting Orientation | Horizontal, Vertical |
| Mounting Orientation - Check Valves | Horizontal, Vertical |
| Mounting Position | Horizontal/Vertical |
| Nsf Certifications For Food And Drinking Water | NSF 61 |
| Operating Temperature - Maximum | 180°F |
| Operating Temperature - Minimum | 35°F |
| Overall Length | 3.5" |
| Pipe Or Tube Size | 1" |
| Pipe Or Tube Size - Check Valves | 1" |
| Poppet Material | 302 Stainless Steel |
| Screen Material | Stainless Steel |
| Seal Material | Buna N |
| Seal Material - Check Valves | Nitrile |
| Seat Material | Bronze |
| Seat Material - Check Valves | Bronze |
| Silent Check | Standard |
| Size | 1" |
| Spring Material | Stainless Steel |
| Spring Material - Check Valves | Stainless Steel |
| Standards | Ansi B1.20.1 |
| Vacuum Service Rating | Not Rated |
| Valve Body Style | Inline |
| Valve Series | 80E |
| Width | 1 3/4" |
| Height (cm) | 12.95 |
|---|---|
| Length (cm) | 5.08 |
| Width (cm) | 5.33 |
| HS Code | 8481301010 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 0.495 |
| Style | Model | Connection Type | Body Material | Pipe Size | Max. Temp. | Seat Material | Seal Material | Flow Rate | Max. Water Pressure | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | CV-3TLF | FNPT x FNPT | Brass | - | 190°F | Bronze | Buna-N | 13 GPM | 200 psi | $34.83 | |
| A | CV-4TLF | FNPT x FNPT | Brass | - | 190°F | Bronze | Buna-N | 18 GPM | 200 psi | $53.63 | |
| A | CV-5TLF | FNPT x FNPT | Brass | 1 1/4" | 190°F | Bronze | Buna-N | 23 GPM | 200 psi | $77.49 | |
| A | CV-6TLF | FNPT x FNPT | Brass | 1 1/2" | 190°F | Bronze | Buna-N | 25 GPM | 200 psi | $106.90 | |
| A | CV-8TLF | FNPT x FNPT | Brass | - | 190°F | Bronze | Buna-N | 30 GPM | 200 psi | $179.23 | |
| B | 4030E | FNPT x FNPT | Bronze | - | 180°F | Bronze | Buna N | 13 GPM | 400 psi | $68.54 | |
| B | 4032E | FNPT | - | - | 180°F | Unleaded Bronze | Nitrile | 23 GPM | - | $141.40 |
