| Item | Fuse |
|---|---|
| Ac Voltage Rating | 600V AC |
| Amps | 4000A |
| Body Material | Fiberglass, Melamine |
| Body Style | Bolt On |
| Class | L |
| Dc Voltage Rating | Not Rated |
| Diameter | 5 3/4" |
| Element | Dual |
| Equivalent Brand And Series | Bussmann Klu, Littelfuse Kllu, Littelfuse Klpc, Mersen A4By |
| Equivalent Series | A4By, Kllu, Klpc, Klu |
| Fits Fuse Block Style | Nonrejection |
| Fuse Class | Class L |
|---|---|
| Fuse Dia. | 5 3/4" |
| Fuse Length | 10 3/4" |
| Fuse Size | 10 3/4" x 5 3/4" |
| Interrupt Rating | 200 kA at 600V AC |
| Length | 10 3/4" |
| Rejection / Nonrejection | Non Rejection |
| Series | KLU Series |
| Speed | Time Delay |
| Speed Type | Fast Acting |
| Standards | Ce/Ul-248-10 Guide Jddz/Csa Class 1422-02 |
| Visual Indication | Non Indicating |
| Height (cm) | 14.6 |
|---|---|
| Length (cm) | 27.3 |
| Width (cm) | 14.6 |
| HS Code | 8536100040 |
|---|---|
| Country Of Origin | MX |
| Weight (kg) | 9.9675 |
| Style | Model | Amps | Diameter | Fuse Length | Speed Type | Fuse Dia. | Dc Voltage Rating | Speed | Interrupt Rating | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | KLU-601 | 601A | 2 1/2" | 8 5/8" | Fast Acting | 2 1/2" | Not Rated | Time Delay | 200 kA at 600V AC | $823.23 | |
| A | KLU-650 | 650A | 2 1/2" | 8 5/8" | Fast Acting | 2 1/2" | Not Rated | Time Delay | 200 kA at 600V AC | $2,346.72 | |
| A | KLU-700 | 700A | 2 1/2" | 8 5/8" | Fast Acting | 2 1/2" | Not Rated | Time Delay | 200 kA at 600V AC | $2,069.26 | |
| B | KLU-3000 | 3000A | 5" | 10 3/4" | Time Delay | 5" | Not Rated | Time Delay | 200 kA at 600V AC | $1,936.13 | |
| A | KLU-800 | 800A | 2 1/2" | 8 5/8" | Fast Acting | - | Not Rated | Time Delay | 200 kA at 600V AC | $840.60 | |
| C | KLU-1000 | 1000A | 2 1/2" | 10 3/4" | Fast Acting | 2 1/2" | Not Rated | Time Delay | 200 kA at 600V AC | $898.91 | |
| C | KLU-1200 | 1200A | 2 1/2" | 10 3/4" | Fast Acting | 2 1/2" | Not Rated | Time Delay | 200 kA at 600V AC | $840.60 |
