| Item | Fuse Block |
|---|---|
| Ac Voltage Rating | 600V AC |
| Amp Range | 0-30A |
| Body Material | Thermoplastic |
| Compatible Fuse Series | BMM603 Series |
| Connector Type | Pressure Plate With Quick Connect |
| Dc Voltage | 300V DC |
| Fits Fuse Type | Midget |
| For Fuse Size | 1 1/2" x 13/32" Dia. |
| Fuse Block Design | Open |
| Fuse Block Style | Nonrejection |
| Fuse Current | 0-30A |
| Fuse Overall Diameter | 13/32" |
| Fuse Overall Length | 3" |
| Fuse Ul Class | Midget |
| Height | 1.3" |
| Housing Material | Thermoplastic |
| Indicating / Nonindicating | Non Indicating |
|---|---|
| Length | 3" |
| Material | Thermoplastic |
| Mounting Style | Bolt-Down, Din Rail |
| Mounting Type | Bolt Down, DIN Rail |
| Number Of Poles | 3 |
| Operating Amps | 0-30A |
| Rejection / Nonrejection | Non Rejection |
| Standards | Ce, Csa Certified, Reach, Rohs, Ul Listed |
| Type | Fuse Block |
| Visual Indication | Non Indicating |
| Voltage | 600V AC/300V DC |
| Voltage Rating | 600V AC/300V DC |
| Width | 2 2/5" |
| Wire Range | 18 AWG to 10 AWG |
| Wire Size | 10 AWG to 18 AWG |
| Height (cm) | 3.3 |
|---|---|
| Length (cm) | 7.62 |
| Width (cm) | 6.1 |
| Country Of Origin | MX |
|---|---|
| Weight (kg) | 0.0945 |
| Style | Model | Number Of Poles | Fuse Block Style | Voltage Rating | Voltage | Wire Range | Fuse Ul Class | Amp Range | Mounting Style | Pkg. Qty. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A | BMM603-1SQ | 1 | Nonrejection | 600V AC/300V DC | 600V AC/300V DC | 18 AWG to 10 AWG | Midget | 0-30A | Bolt-Down, Din Rail | 1 | $17.47 | |
| A | BMM603-3SQ | 3 | Nonrejection | 600V AC/300V DC | 600V AC/300V DC | 18 AWG to 10 AWG | Midget | 0-30A | Bolt-Down, Din Rail | 1 | $64.44 | |
| B | BMM603-1C | 1 | Non Rejection | 600V AC/DC | 600V AC/DC | 14 AWG to 2 AWG | Midget | 0-30A | Bolt-Down, Din Rail | 1 | $38.24 | |
| C | BMM603-2SQ | 2 | Non Rejection | - | 600V AC/DC | 18 AWG to 10 AWG | Midget | 0-30A | - | 1 | $30.60 | |
| C | BMM603-2C | 2 | Non Rejection | 600V AC/DC | 600V AC/DC | 2 AWG to 14 AWG | Midget | 0-30A | Bolt-Down, Din Rail | 1 | $75.44 | |
| D | BMM603-3C | 3 | Non Rejection | 600V AC/DC | 600V AC/DC | 14 AWG to 2 AWG | Midget | 0-30A | Bolt-Down, Din Rail | 1 | $128.07 | |
| A | BMM603-1PQ | 1 | Nonrejection | 600V AC/300V DC | 600V AC/300V DC | 18 AWG to 10 AWG | Midget | 0-30A | Bolt-Down, Din Rail | 1 | $23.30 |
