| Item | In-Line Ventilator |
|---|---|
| Cfm @ 0.000-in. Sp | 546 CFM |
| Cfm @ 0.100-in. Sp | 526 CFM |
| Cfm @ 0.125-in. Sp | 519 CFM |
| Cfm @ 0.375-in. Sp | 472 CFM |
| Cfm @ 0.500-in. Sp | 447 CFM |
| Cfm @ 0.625-in. Sp | 407 CFM |
| Cfm @ 0.750-in. Sp | 364 CFM |
| Cfm @ 1.000-in. Sp | 232 CFM |
| Discharge Direction | Horizontal |
| Duct Dia. | 10" |
| Duct Height | 4 1/2" |
| Duct Shape | Rectangular |
| Duct Width | 18 1/2" |
| Exhaust Airflow @ 0.000 In Sp | 546 CFM |
| Exhaust Airflow @ 0.100 In Sp | 526 CFM |
| Exhaust Airflow @ 0.250 In Sp | 494/496 CFM |
| Fan Wattage | 232 W |
| Frequency | 60 Hz |
| Full Load Amps | 2.2A |
| Housing Finish | Galvanized |
| Housing Height | 11 3/4" |
| Housing Length | 12 1/4" |
| Housing Material | Steel |
| Inlet Height | 4 1/2" |
| Max. Inlet Temp. | 104°F |
| Maximum Airflow | 546 CFM |
| Maximum Noise Level | 3.4 sones |
| Motor Enclosure Design | Open |
| Motor Insulation | Class B |
|---|---|
| Motor Output Power | 232 W |
| Motor Speed | 890 RPM |
| Motor Type | Permanent Split Capacitor |
| Mounting Position | Remote In Line |
| Mounting Type | Mounting Brackets |
| Noise Level @ 0.000 In Sp @ 5 Ft | 2.9 sones |
| Noise Level @ 0.100 In Sp @ 5 Ft | 2 sones |
| Noise Level @ 0.125 In Sp @ 5 Ft | 3.4 sones |
| Noise Level @ 0.250 In Sp @ 5 Ft | 3.7 sones |
| Number Of Speeds | 1 |
| Outlet Width | 18 1/2" |
| Overall Depth | 12 1/4" |
| Overall Height | 11 3/4" |
| Overall Width | 21 1/2" |
| Phase | 1 |
| Profile Height Family | Low |
| Profile Width Family | Double Wide |
| Sones @ 0.000-in. Sp @ 5 Ft. | 2.4 sones |
| Sones @ 0.100-in. Sp @ 5 Ft. | 2.4 sones |
| Sones @ 0.250-in. Sp @ 5 Ft. | 3.7 sones |
| Speed Control | 4C331 Or 6E897 |
| Standards | Ul/Cul |
| Type | In Line |
| Voltage | 120V AC |
| Wattage | 232 W |
| Wheel Dia. | 7.812" |
| Wheel Material | Polymer |
| Height (cm) | 39.37 |
|---|---|
| Length (cm) | 64.77 |
| Width (cm) | 42.16 |
| HS Code | 8414513000 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 14.715 |
| Style | Model | Sones @ 0.100-in. Sp @ 5 Ft. | Cfm @ 0.000-in. Sp | Cfm @ 0.100-in. Sp | Cfm @ 0.375-in. Sp | Cfm @ 0.125-in. Sp | Motor Speed | Sones @ 0.000-in. Sp @ 5 Ft. | Sones @ 0.250-in. Sp @ 5 Ft. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | L400L | 1.6 sones | - | 415 CFM | 313 CFM | 406 CFM | 775 RPM | 1.4 sones | 1.9 sones | $611.56 | |
| A | L700L | 3.8 sones | 704 CFM | 686 CFM | 631 CFM | 681 CFM | 1090 RPM | 3.6 sones | 3.9 sones | $724.41 |
