| Item | Hypoid Gearmotor |
|---|---|
| Application | Chip Auger, Conveyor, Industrial, Light Industry, Packaging |
| Base To Center Of Shaft | 2.11" |
| Bearing Type | Ball |
| Capacitor Required | Yes |
| Compatible Capacitor | 41C241 |
| Duty Condition Type | Continuous Duty |
| Enclosure Type | Totally Enclosed Fan Cooled |
| Finish | Powder Coat, Anodized |
| Frame | 39F |
| Frequency | 60 Hz |
| Full Load Amps | 1.86A |
| Gear Material | Hardened Steel |
| Gear Ratio | 180:1 |
| Gear Type | Hypoid |
| Housing Material | Die Cast Aluminum |
| Housing Material Finish | Gearbox Powder Coated Paint, Motor Anodized |
| Input Hp | 1/8 hp |
| Input Power | AC |
| Insulation Class | Class B4 |
| Inverter Rated | No |
| Keyway Depth | 1" |
| Keyway Size | 0.25" x 1" |
| Keyway Type | 0.25 Sq. in. x 1" |
| Keyway Width | 1/4" |
| Length Less Shaft | 13.63" |
| Lubrication | Powerstar EP For Extended Life |
| Max. Ambient Temp. | 40°C |
| Maximum Ambient Temperature | 104°F |
| Maximum Torque | 680 lbs.-in. |
| Motor Enclosure | Totally Enclosed Fan Cooled |
| Motor Insulation Class | Class F |
| Motor Type | Permanent Split Capacitor |
|---|---|
| Mount Hole Center-to-center Length | 5.47" |
| Mount Hole Center-to-center Width | 3.35" |
| Mount Type | Any Position |
| Mounting | All Position |
| Mounting Orientation | Any Angle |
| Nameplate Rpm | 9 RPM |
| Nameplate Speed | 9.3 RPM |
| No Load Speed | 9.3 RPM |
| Operating Voltage | 115V AC |
| Output Shaft Diameter | 1" |
| Output Shaft Type | Hollow |
| Overall Height | 6.66" |
| Overall Length | 13.62" |
| Overall Width | 4.64" |
| Overhung Load | 870 lbs. |
| Overhung Load Capacity | 870 lbs.-ft. |
| Phase | 1 |
| Replacement Brushes | Not Applicable |
| Reversible Shaft Output | Yes |
| Rotation | CW/CCW |
| Rpm Range | 0-15 RPM |
| Seal Type | Double Lip |
| Seals | Double Lip |
| Shaft | Hollow Output |
| Shaft Orientation | Right Angle |
| Square Size | 0.25" x 1" |
| Thermal Protection | No |
| Torque | 680 lbs.-in. |
| Voltage | 115V |
| Brake Type | None |
| Standards | C-UL RECOGNIZED, CE CERTIFIED, UL RECOGNIZED |
| Height (cm) | 16.92 |
|---|---|
| Length (cm) | 34.59 |
| Width (cm) | 11.79 |
| HS Code | 8501403020 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 9 |
| Style | Model | Gear Ratio | Rotation | Mounting Orientation | Operating Voltage | Inverter Rated | Motor Type | Overhung Load Capacity | Base To Center Of Shaft | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 026-725A0100 | 100:1 | CW/CCW | Any Angle | 115V AC | No | Permanent Split Capacitor | 740 lbs.-ft. | 2.11" | $1,443.99 | |
| A | 026-725A0120 | 120:1 | CW/CCW | Any Angle | 115V AC | No | Permanent Split Capacitor | 780 lbs.-ft. | 2.11" | $1,485.30 | |
| A | 026-725A0150 | 150:1 | CW/CCW | Any Angle | 115V AC | No | Permanent Split Capacitor | 820 lbs.-ft. | 2.11" | $1,485.30 | |
| A | 026-725A0240 | 240:1 | CW/CCW | Any Angle | 115V AC | No | Permanent Split Capacitor | 940 lbs.-ft. | 2.11" | $1,485.30 | |
| A | 026-725A0010 | 10:1 | CW/CCW | Any Angle | 115V AC | No | Permanent Split Capacitor | 355 lbs.-ft. | 2.11" | $1,845.94 | |
| A | 026-725A0015 | 15:1 | CW/CCW | Any Angle | 115V AC | No | Permanent Split Capacitor | 400 lbs.-ft. | 2.11" | $1,533.60 | |
| A | 026-725A0020 | 20:1 | CW/CCW | Any Angle | 115V AC | No | Permanent Split Capacitor | 430 lbs.-ft. | 2.11" | $1,608.91 |
