| Item | Hot Water Circulator Pump |
|---|---|
| Amps | 1.8A |
| Best Efficiency Flow Rate @ Head | 35 GPM @ 12 ft. |
| Compatible Discharge Pipe Size | 1", 1 1/4", 1 1/2" |
| Compatible Pipe Size | 1", 1 1/4", 1 1/2" |
| Connection Type | Flanged |
| Drive Type | Direct |
| Enclosure Type | Totally Enclosed Fan Cooled |
| Face To Face Dimension | 8 1/2" |
| Flange Or Union Included | No |
| For Pipe Size | 1", 1 1/4", 1 1/2" |
| For Use With Potable Systems | Yes |
| Frequency | 60 Hz |
| Housing Material | Cast Iron |
| Hp | 1/6 hp |
| Impeller Material | Plastic |
| Includes | Auto Thermal Protection |
| Loop Configuration | Closed |
| Manufacturer Warranty Length | 1 yr. |
| Max. Flow Rate @ 1 Ft. | 58 GPM |
| Max. Flow Rate @ 10 Ft. | 40 GPM |
| Max. Flow Rate @ 15 Ft. | 20 GPM |
| Max. Flow Rate @ 5 Ft. | 50 GPM |
| Max. Flow Rate @ Head | 58 GPM @ 1 ft. |
| Max. Head | 17 ft. |
| Max. Media Temp. | 225°F |
|---|---|
| Max. Operating Pressure | 150 psi |
| Max. Rpm | 3300 RPM |
| Max. Temp. | 225°F |
| Maximum Flow Rate @ 5 Feet Of Head | 50 GPM |
| Mechanical Seal | Maintenance Free |
| Min. Flow Rate @ Head | 20 GPM @ 15 ft. |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Mounting Location | Inline |
| Mounting Material | Nonmetallic |
| No. Of Speeds | 1 |
| Overall Height | 8 1/2" |
| Overall Length | 9.13" |
| Overall Width | 4 1/2" |
| Phase | 1 |
| Phase And Brand | Bell & Gossett Single Phase |
| Pump Housing Material | Cast Iron |
| Pump Size | 1AAB |
| Pump Type | Standard |
| Rotor Type | Dry |
| Series | PL-50 Series |
| Series Family | PL |
| Shut-off | 17 ft. |
| Thermal Protection | Automatic |
| Voltage | 115V AC |
| Height (cm) | 12.95 |
|---|---|
| Length (cm) | 24.64 |
| Width (cm) | 22.86 |
| HS Code | 8413810040 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 7.02 |
| Style | Model | Hp | Face To Face Dimension | Housing Material | Amps | Compatible Discharge Pipe Size | Max. Flow Rate @ 5 Ft. | Max. Flow Rate @ 10 Ft. | Max. Flow Rate @ 1 Ft. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | PL-30 | 1/12 hp | 6 3/8" | Cast Iron | 1.4A | 3/4", 1", 1 1/4", 1 1/2" | 25 GPM | 20 GPM | 30 GPM | $994.05 | |
| A | PL-36 | 1/6 hp | 6 3/8" | Cast Iron | 2.1A | 3/4", 1", 1 1/4", 1 1/2" | 37 GPM | 34 GPM | 38 GPM | $1,033.94 | |
| A | PL-45 | 1/6 hp | 8 1/2" | Cast Iron | 2.1A | 1", 1 1/4", 1 1/2" | 45 GPM | 43 GPM | 49 GPM | $1,244.40 | |
| B | PL-30B | 1/12 hp | 6 3/8" | Bronze | 1.4A | 3/4", 1", 1 1/4", 1 1/2" | 25 GPM | 20 GPM | 30 GPM | $1,588.04 | |
| B | PL-36B | 1/6 hp | 6 3/8" | Bronze | 2.1A | 3/4", 1", 1 1/4", 1 1/2" | 37 GPM | 34 GPM | 38 GPM | $1,576.60 | |
| B | PL-45B | 1/6 hp | 8 1/2" | Bronze | 2.1A | 1", 1 1/4", 1 1/2" | 45 GPM | 43 GPM | 49 GPM | $1,870.11 | |
| B | PL-50B | 1/6 hp | 8 1/2" | Bronze | 1.8A | 1", 1 1/4", 1 1/2" | 50 GPM | 40 GPM | 58 GPM | $2,152.86 |
