| Item | General Purpose Motor |
|---|---|
| Ac/dc | AC |
| Ambient Temp. | 40°C |
| Amps | 6.6/3.3A |
| Amps @ 208v | 4.5A |
| Auto | Yes |
| Base Type | Not Applicable |
| Break-down Torque | 2.57 lbs.-ft. |
| Class | Stock |
| Code | M |
| Conduit Box Position | F1 |
| Design Code | N |
| Duty | Continuous |
| Efficiency | 72% |
| Efficiency @ 100% Load | 72% |
| Enclosure Design | Open |
| Frame | 56Y |
| Frame Material | Steel |
| Frame Size | 56Y |
| Frequency | 60 Hz |
| Full Load Amps | 6.6/3.3A |
| Full Load Torque | 0.764 lbs.-ft. |
| Hp | 1/2 hp |
| Insulation Class | Class B |
| Inverter Code | Not Inverter |
| Lead | 5#18, 1#16 #1Th |
| Line-line Res. @ 25° C | 3.74 ohms A Ph/3.44 ohms B Ph |
| Locked-rotor Torque | 1.04 lbs.-ft. |
| Motor Enclosure Design | Open Air Over |
| Motor Type | Capacitor Start/Induction Run |
| Mounting Type | Square Flange |
| Multiplier | K |
|---|---|
| Nameplate Rpm | 3450 RPM |
| Nema/iec | NEMA |
| No Load Amps | 2.38A |
| No. Of Motor Leads | 5 |
| No. Of Poles | 2 |
| No. Of Speeds | 1 |
| Overall Length | 11.35" |
| Phase | 1 |
| Power Factor | 69 |
| Proprietary | No |
| Pull-up Torque | 0.763 lbs.-ft. |
| Pulley Face Code | Other |
| Revision | M |
| Rpm | 3400-3600 RPM |
| Service Factor | 1.6 |
| Sf Amps | 8.6/4.3A |
| Shaft Dia. | 5/8" |
| Shaft Ground Indicator | No Shaft Grounding |
| Shaft Rotation | Fixed Opposite Standard |
| Start Configuration | DOL |
| Starting Amps | 17.9A |
| Synchronous Rpm | 3600 RPM |
| Temp. Rise @ Rated Load | 51°C |
| Temp. Rise @ S. F. Load | 73°C |
| Thermal Protection | Automatic |
| Type | 1716L |
| Voltage | 115/230V |
| Wire Size | 18 AWG |
| Base Indicator | None |
| Height (cm) | 28.26 |
|---|---|
| Length (cm) | 41.91 |
| Width (cm) | 29.21 |
| HS Code | 85013100 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 10.8 |
