| Item | General Purpose Motor |
|---|---|
| Ac/dc | AC |
| Ambient Temp. | 40°C |
| Amps | 111A |
| Base Indicator | Rigid |
| Base Type | Rigid Base |
| Break-down Torque | 364 lbs.-ft. |
| Conduit Box Material | Cast Iron |
| Conduit Box Position | F1 |
| Design Code | A |
| Duty | Continuous |
| Enclosure Design | TEFC |
| Frame | 324T |
| Frame Material | Iron |
| Frame Size | 324T |
| Frequency | 60 Hz |
| Full Load Amps | 111A |
| Full Load Torque | 118 lbs.-ft. |
| Grease Type | Polyrex EM |
| Hp | 40 hp |
| Insulation Class | Class F |
| Inverter Code | Inverter Ready |
| Kva Code | H |
| Lead | 3#4 |
| Line-line Res. @ 25° C | 0.027 ohms A Ph/0 ohms B Ph |
| Locked-rotor Torque | 183 lbs.-ft. |
| Lubrication | Polyrex EM |
| Mounting Type | Foot Mounted |
| Multiplier | L1 |
|---|---|
| Nameplate Rpm | 1775 RPM |
| Nema/iec | NEMA |
| No Load Amps | 43.8A |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 94.1% |
| Overall Length | 30.28" |
| Phase | 3 |
| Power Factor | 82 |
| Proprietary | No |
| Pull-up Torque | 172 lbs.-ft. |
| Pulley Face Code | Standard |
| Revision | D |
| Rpm | 1700-1800 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 2 1/8" |
| Shaft Ground Indicator | No Shaft Grounding |
| Shaft Rotation | Reversible |
| Start Configuration | DOL |
| Starting Amps | 758A |
| Synchronous Rpm | 1800 RPM |
| Temp. Rise @ Rated Load | 53°C |
| Temp. Rise @ S. F. Load | 64°C |
| Type | 1254M |
| Voltage | 200V |
| Wire Size | 4 AWG |
| Xp Class And Group | None |
| Height (cm) | 58.42 |
|---|---|
| Length (cm) | 87.63 |
| Width (cm) | 67.31 |
| HS Code | 85015230 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 258.3 |
