| Item | General Purpose Motor |
|---|---|
| Ambient Temp. | 40°C |
| Base Indicator | Rigid |
| Bearing Type | Ball |
| Conduit Box Material | Steel |
| Conduit Box Position | F1 |
| Design Code | A |
| Duty | Continuous |
| Efficiency | 95.4% |
| Enclosure Design | OPSB |
| Frame | 404T |
| Frame Material | Steel |
| Frame Size | 404T |
| Frequency | 60 Hz |
| Full Load Amps | 115A |
| Hp | 100 hp |
| Insulation Class | Class H |
| Inverter Code | Inverter Ready |
| Motor Enclosure Design | Open Dripproof |
| Motor Shaft Rotation | Clockwise/Counter Clockwise |
|---|---|
| Mounting Type | Foot Mounted |
| Nameplate Rpm | 1780 RPM |
| Nema/iec | NEMA |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Overall Length | 36.97" |
| Phase | 3 |
| Power Factor | 83 |
| Pulley Face Code | Standard |
| Rpm | 1700-1800 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 2 7/8" |
| Shaft Ground Indicator | Shaft Grounding |
| Shaft Rotation | Reversible |
| Synchronous Rpm | 1800 RPM |
| Thermal Protection | None |
| Voltage | 460V |
| Height (cm) | 65.09 |
|---|---|
| Length (cm) | 103.19 |
| Width (cm) | 82.55 |
| HS Code | 85015230 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 404.1 |
